Modulation Page
As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-
ity.
Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From that mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
10.4.4 Creating a Pattern with Closed and Open Hi-hats
Don’t hesitate to use a few Hi-hat Plug-ins within a Choke group! Indeed, by loading two Hi-hat
Plug-ins with different settings in two different Sounds (one for the closed hi-hat, one for the
open hi-hat), then assigning both Sounds to the same Choke group, and leaving both as Master
in the group, you can recreate mutually exclusive hi-hat sounds that cancel each other out
when played, like on a real drum set. By the way you are not limited to two hi-hat sounds —
e.g., you could add to the same Choke group a third Sound containing a half-opened hi-hat. To
know how to do this, please refer to section ↑5.1.4, Using Choke Groups where Choke groups
are explained in detail.
With a single Hi-hat Plug-in, you could also recreate an open-closed hi-hat behavior by dis-
abling Gate and modulating the Decay in your Pattern. This rather advanced task might
give you even finer control over the duration of your various hi-hat sounds, and thereby help
you to give your hi-hat track a “human” feel. Furthermore, since this method makes use of
a single Sound you can quickly modify other parameters of your Hi-hat Plug-in — your
changes will seamlessly apply to all your hi-hat variants!
10.5 The Toms
The Tom Drumsynth can generate a variety of tom sounds.
Using the Drumsynths
The Hi-hats
MASCHINE STUDIO - Manual - 480
