▪ Tronic (default): ↑10.5.1, Tom – Tronic.
▪ Fractal: ↑10.5.2, Tom – Fractal.
▪ Floor: ↑10.5.3, Tom – Floor.
For more information on engines, see ↑10.1.1, Engines: Many Different Drums per Drum-
synth. For general information on the Snare and the other Drumsynths, see ↑10.1, Drum-
synths – General Handling.
10.5.1 Tom – Tronic
The Tronic engine is the default engine of the Tom.
A fat, analog-style tom with two tunable oscillators plus a tunable FM oscillator.
The parameters described below are presented as they appear in the Control area (Arrange
view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix
view). See ↑9.4, The Plug-in Strip for more information on this.
Main Page
Element Description
MAIN Section
Engine Selects the engine used in the Tom Plug-in. If you change this setting, please
refer to ↑10.5, The Toms.
Tune Adjusts the pitch of the drum played by the middle C, measured in MIDI note
numbers and cents. Available values range from 36.00 to 60.00. The default
value is 36.00. For more details see ↑10.1.5, Pitch Range, Tuning, and MIDI
Notes.
Decay Adjusts the duration of the sound’s tail, measured as a percentage. Available
values range from 0.0 to 100.0 % (default: 50.0 %).
Using the Drumsynths
The Toms
MASCHINE STUDIO - Manual - 482
