10.5.3 Tom – Floor
The Floor Tom is an acoustic tom that provides the emulation of a complete set of toms. Al-
though it is more suitable for floor and low toms, it is also capable of producing interesting
mid and high toms. Furthermore the control over the pitch bend and the mute parameters al-
low for a wide range of sounds.
The parameters described below are presented as they appear in the Control area (Arrange
view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix
view). See ↑9.4, The Plug-in Strip for more information on this.
Main Page
Element Description
MAIN Section
Engine Selects the engine used in the Tom Plug-in. If you change this setting, please
refer to ↑10.5, The Toms.
Tune Adjusts the pitch of the drum played by the middle C, measured in MIDI note
numbers and cents. Available values range from 48.00 to 62.00. The default
value is 48.00. For more details see ↑10.1.5, Pitch Range, Tuning, and MIDI
Notes.
Decay Adjusts the duration of the sound’s tail, measured as a percentage. Available
values range from 0.0 to 100.0 % (default: 50.0 %).
Tension Adjusts the tension of the drum skin, measured as a percentage, allowing for a
longer and bigger pitch bend. Available values range from 0.0 to 100.0 % (de-
fault).
Impact Adjusts how hard the drum is hit, measured as a percentage. Available values
range from 0.0 % (softest) to 100.0 % (hardest). The default value is 80.0 %.
Flex Adjusts the elasticity of the skin, measured as a percentage, allowing for a
greater pitch bend when the drum is hit. Available values range from 0.0 to
100.0 % (default: 30.0 %).
MUTE Section
