2. Press NAVIGATE + pad 1 to select the Audio Parameter page. You can also press the Page
Left button until it turns off, since the Audio page is the first page of the Input properties.
You will now see two parameters at the bottom of the left display: SOURCE (which selects
the source) and GAIN (which adjusts the level of the input).
3.
Turn Knob 1 to set the SOURCE to Ext. 1.
→
Now the external audio is routed to your Sound! You can adjust the level of the incoming
signal by turning Knob 2 (GAIN).
11.2.3 Step 3: Load an Effect to Process an Input
You can now insert an Effect Plug-in into this Sound so that it processes the incoming audio.
Here we describe the procedure in Arrange view. You can also do this in Mix view — see
section ↑11.1.1, Adding an Effect.
→
Upon your selection the effect is loaded in a new Plug-in slot and directly starts to proc-
ess your external audio!
Using Effects
Applying Effects to External Audio
MASCHINE STUDIO - Manual - 514
