The Sound slot now mirrors the Plug-in name.
For more information on renaming Sound slots, see section ↑4.2.3, Renaming Sound Slots.
11.3.2 Step 2: Route Audio to the Send Effect
Once you have configured a Sound or Group as send effect (see ↑11.3.1, Step 1: Set Up a
Sound or Group as Send Effect above), you can send the output of any other Sounds and
Groups to that Sound or Group. For this purpose, each Sound and each Group is equipped with
an additional two auxiliary outputs available in its Output properties.
Here we describe the procedure in Arrange view. You can also do this in Mix view — see
section ↑8.1.2, Configuring the Main Output of Sounds and Groups.
You can repeat the process to route more Sounds/Groups to the same send effect, or route the
same Sound/Group to an additional send effect send using AUX 2.
11.3.2.1 Routing Audio to the Send Effect on the MASCHINE STUDIO Controller
1. Press the CHANNEL button to enter Control mode and display the Channel properties.
2. If you want to route a Group’s output to the send effect, press Button 2 to select the
GROUP tab, if necessary press SHIFT + the Group button A–H corresponding to the bank
containing the Group, and press the Group button A–H corresponding to the desired
Group.
3. If you want to route a Sound’s output to the send effect, press Button 3 to select the
SOUND tab, select the Group containing that Sound as described in the previous step, and
press SELECT + the pad of that Sound (or simply press its pad if pads are in Group
mode).
Using Effects
Creating a Send Effect
MASCHINE STUDIO - Manual - 520
