12.3 Modulation Effects
12.3.1 Chorus
The Chorus is useful to “thicken” signals and enhance or add stereo content. It is most effec-
tive on melodic sounds, but can also be used on hi-hats to make them more vivid or on a voice
sample to create a doubling effect (thereby making it sound as if there were several voices). It
works by splitting the audio signal up into two versions and slightly detuning one of them.
The Chorus panel in the Plug-in Strip.
The Chorus in the Control area.
Parameter
Description
MOD Section
Rate The Rate knob defines how fast the phase (and thus the perceived pitch) of the
detuned signal is being modulated.
Amount The amount of the Chorus effect.
Effect Reference
Modulation Effects
MASCHINE STUDIO - Manual - 550
