12.4 Spatial and Reverb Effects
12.4.1 Ice
This is a special reverb for getting cold and metallic sound. Ice includes a bank of self-oscillat-
ing filters for interesting and colorful effects. In the Project “Come Into My Disco” from the
MASCHINE factory library, you can hear how it creates deep soundscapes during the break in
Scene 6.
The Ice panel in the Plug-in Strip.
The Ice in the Control area.
Parameter
Description
ROOM Section
Color With lower settings, the general sound is a bit more muffled. The higher
the Color value, the brighter it sounds.
Ice The “ICE” factor: higher values sound more metallic.
Effect Reference
Spatial and Reverb Effects
MASCHINE STUDIO - Manual - 558
