◦ Horizontally, the displayed time interval is variable: Turn Knob 5 and 6 to zoom and
scroll in the right display to your liking, respectively. You can also enable Button 3
(FOLLOW) and let the right display follow the playhead as it travels through your ar-
rangement — see section ↑13.1.3, Following the Playback Position in Your Project for
more information.
◦ At the top of the right display you see the Scenes names (7) with the timeline (8) un-
derneath. The name of the selected Scene is underlined. As in the left display, you
can see the vertical playhead indicator (6) and the Loop Range (10) across the entire
display.
◦ As in the software’s Arranger, each Clip (9) shows the name and color of the Pattern it
is referencing. The selected Clip (i.e. the Clip in the selected Scene for the focused
Group) is highlighted. By pressing Button 2 (PATTERN) or the ENTER button under the
jog wheel you can switch to Pattern Arrange mode and control the content of the Pat-
tern referenced by this selected Clip — see section ↑7.1.1, Pattern Editor Overview.
To know how to modify the name and color of your Patterns, please refer to section ↑7.7.6,
Naming Patterns and ↑7.7.7, Changing the Pattern’s Color, respectively.
Furthermore, the pads on your controller represent the Scenes of the current Scene bank:
▪ The fully lit pad indicates the selected Scene slot.
▪ Dim lit pads indicate Scene slots containing a Scene.
▪ Unlit pads represent empty Scene slots.
In addition, the Scene Arrange mode provides useful Scene management commands. These
are described in the following sections.
Scene Mode
Although sharing many features with the Scene Arrange mode described above, the Scene
mode focuses on Scene selection and manipulation rather than on their arrangement.
►
To enter Scene mode on your controller, press and hold SCENE (you can pin it by press-
ing Button 1 at the same time).
→
Your controller switches to Scene mode. This is indicated by the lit SCENE button.
Creating a Song Using Scenes
Managing Scenes
