Parameter Description
BPM (BPM Mode) Selects how the tempo is defined: If you select Auto, MASCHINE will calculate
the tempo automatically. If you select Manual, you can enter the tempo in BPM
manually.
ADJUST If BPM is set to Auto, you can choose between the tempo that MASCHINE de-
tected, or half or double of that tempo. If BPM is set to Manual, you can adjust
the tempo manually.
ENGINE Section (Detect mode only)
ZERO-X (Zero Crossing,
Detect mode only)
When MODE is set to Detect, activate ZERO-X to force the detected Slices to be
created on the closest locations where the audio signal crosses the zero value.
This can be helpful to avoid clicks when playing back Slices in another se-
quence.
14.4.2.1 Adjusting the Slicing Settings on Your Controller
At the bottom of the left display, you can adjust the settings used to define where the various
Slices will be created in the Sample.
Adjust the slicing settings via Knob 1–4.
Any change to these settings will directly affect the number and position of the Slice markers
shown in the waveform on the displays.
Selecting and Pre-Listening the Slices with the Pads
At any time, the proposed Slices are also available on your pads: The fully lit pad indicates the
selected Slice, while the dim lit pads indicate the other Slices.
Sampling and Sample Mapping
Slicing a Sample
MASCHINE STUDIO - Manual - 666
