Installation Manual

4
Attaching TV to TV Plate
S t e p 4
Mounting the Monitor Brackets to a TV
S t e p 3
First, make sure you have the correct diameter bolt (l to q) your TV requires. Once you have the correct size, please see
the diagram below. You will then thread the bolt into the TV using the correct washers (r,s,t), and using the spacer (u,v) if
necessary. Please make sure the monitor brackets are vertically centered and level with each other.
r, s ,t
l t o q
u,v
S afety
B olt
4.3
b
4.1
4.2
