iCN 550 with Smart™ 2005 Release 2 for iCN 550 User Manual English - United States / Canada
iCN 550 User Manual Contents Box Contents ............................................................................ 5 1. Introduction ........................................................................... 7 2. iCN Features ........................................................................ 8 3. Starting your iCN................................................................. 12 4. Setting your Destination ...................................................... 15 By Address ...................
iCN 550 | User Manual Important Safety Information Please Read Carefully Before Installing Product in Vehicle This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. W WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
iCN 550 User Manual This user manual will help you Drive-Away™ with your iCN, straight out of the box. Navman welcomes your feedback. To contact us or visit our website, see Support Information on page 74. Box Contents USB Cable Protective Carry-Case AC Power Pack with Power Cable Note: The number of plugs depends on the country of purchase.
Getting started iCN 550 User Manual 6
iCN 550 User Manual Whether you travel in your own country or elsewhere, the iCN will direct you to your destination without the need for map-books and second-hand instructions. The Global Positioning System (GPS) is available free of charge, at any time, and is accurate to within 5 m (15 ft). The maps on your iCN provide street-level detail for door-to-door navigation, including Points of Interest (POIs) such as accommodation, gas stations, railway stations and airports.
Getting started iCN 550 User Manual 2. iCN Features We recommend that you familiarise yourself with the iCN’s basic operations, such as using the stylus, 4-way toggle and Volume control. Front Components Component Description Displays maps and menu options. 1 Touch Screen 2 Fuel Displays the Select POI screen, listing the nearest gas stations to your current position. 3 Park Displays the Select POI screen, listing the nearest public parking lot to your current position.
iCN 550 User Manual Description 4-Way Toggle Selects Main Menu options, keyboard characters and preferences, moves around the 2D Map screen to select a destination, and scrolls through lists, such as lists of search results. Press center to confirm the selected menu option, text or preference; press up or down to adjust the viewing angle on the 3D Map screen.
Getting started iCN 550 User Manual Back Components Component Description 1 Battery Switch Must be set to ON for normal use. Switching to OFF will turn the battery off, saving battery power. 2 Speaker Outputs voice commands and warnings. Use the Volume control to adjust. 3 GPS Receiver Receives signals from GPS satellites when lifted out to the horizontal position. 4 External Antenna Socket Connection socket for GPS mMCX External Antenna (not included; see page 65).
iCN 550 User Manual The stylus is your input device. Pull the stylus out of the slot and extend it for ease of use. Store it in the slot when not in use. • Tap the screen with the stylus to select. • Tap and drag the screen with the stylus to navigate the 2D Map and 3D Map screens. Internal Battery The iCN has an internal battery that when fully charged should power the iCN for 4 hours.
Getting started iCN 550 User Manual 3. Starting your iCN Before you begin, check if your vehicle is fitted with a heat-reflective or heated windshield. If so, you will need to purchase an external antenna for your iCN to receive GPS signals. See page 65. Step One: Position the iCN in your Vehicle Follow the safety notice on page 7 to ensure that the iCN does not obstruct the driver’s view, or interfere with the operation of vehicle airbags and safety devices.
iCN 550 User Manual 1. Read the warning message. 2. Tap Accept to confirm that you understand. The first Tutorial Tutorial screen will display. Step Four: Tutorial Screens 1. Read the Tutorial screen. • To prevent the Tutorial from displaying on startup, select the Do not show Tutorial on startup check box. • You can view the Tutorial again while using your iCN. See page 54 for details. 2. Tap to move through each Tutorial screen. The Main Menu screen will display.
Getting started iCN 550 User Manual To Turn your iCN Off When your iCN is off, it enters a suspended state and the system stops operating. When you turn your iCN on, it returns to the screen you were last viewing. 1. Remove the iCN from the suction-mount bracket if necessary, then gently push the GPS receiver back towards the iCN. The receiver will click into place. 2. Press . The iCN will enter a suspended state and the screen will turn off.
iCN 550 User Manual For your safety, enter destination information before you start a journey. Do not operate the iCN while driving. Select a destination using the Destination, Keyboard and Preview screens, which used together form a destination wizard. This section describes how to use each of these screens and provides two case studies to help guide you through setting your destination.
Getting started iCN 550 User Manual Figure 3. Number/Symbol Keyboard As you select each character, the first two results will display. Tap to see more search results. • To select a character or a search result, tap the character or search result. • To delete a character, press ESC or tap <<; hold ESC to delete the line. • To display the number/symbol Keyboard screen (Figure 3), tap 123. • To display the alternate Keyboard screen (Figure 2), press +, or tap Alt.
iCN 550 User Manual Step One: Open the Destination screen a. From the Main Menu, tap Go To. b. From the Go To screen, tap Address or POI. The Destination screen will display. Important Note: The first time you are setting your destination, the Select Country screen will d display instead of the Destination screen. Go to Step Two: Select the Country of Destination, step b. The next time you perform this procedure, the Destination screen will open as expected. Step Two: Select the Country of Destination a.
Getting started iCN 550 User Manual Step Four: Find the Town or City of Destination a. From the Destination screen, tap Find town/city. The Keyboard screen will display. b. Use the Keyboard screen to find the town or city of your destination. For information on using the Keyboard screen, see pages 15-16. The Destination screen will display. Step Five: Find the Street of Destination a. From the Destination screen, tap Find street. The Keyboard screen will display. b.
iCN 550 User Manual Getting started Step Six: Find the House Number of Destination a. From the Destination screen, tap Enter house number. The Keyboard screen will display. Note: If the Enter house number option is not displayed, house numbers are not available for your selected street. Tap Go to center of street to display the Preview screen. Go to step c. b. Use the Keyboard screen to find the house number of your destination. For information on using the Keyboard screen, see pages 15-16.
Getting started iCN 550 User Manual Setting your Destination by POI A POI is a named site, feature, landmark or public venue which can be displayed as an icon on the map. POIs are grouped by type, such as parks and museums. Step One: Open the Destination screen a. From the Main Menu, tap Go To. b. From the Go To screen, tap Address or POI. The Destination screen will display.
iCN 550 User Manual Note: To narrow the search for a type of POI, you can first search by Town or City City. a. From the Destination screen, tap Find Point of Interest. The Select POI screen will display. b. Select a POI type from the list. The Keyboard screen will display. c. Use the Keyboard screen to find the POI. For information on using the Keyboard screen, see pages 15-16. The Preview screen will display.
Getting started iCN 550 User Manual d. Complete one of the following: • To calculate the route and open the 3D Map screen, tap Go. The 3D Map screen will display. • To display the destination on the 2D Map screen, tap the preview map. The 2D Map screen will display. • To save the destination as a Favorite, tap Save. The New Favorite screen will display. See Favorites and My Home on page 37. • To change your destination, tap ESC. The Destination screen will display.
iCN 550 User Manual You can plan a route directly from the 2D Map screen using the Pop-up menu. 1. From the Main Menu, tap Map. The 2D Map screen will display. • Move around the 2D Map screen using the 4-way toggle or stylus. • To display a smaller area in greater detail, press +. • To display a larger area in less detail, press -. 2. Tap the Map screen or press the 4-way toggle button to display the cross-hairs. • To remove the cross-hairs press ESC. 3.
iCN 550 User Manual 6. Multi-stop Trips You can use the Multi-stop Trip screen to set multiple destination points for your trip. Your route will be calculated to go via each of these points in the specified order. Destination points can be added via the Multi-stop Trip screen or by selecting Show Details from the pop-up menu on the 2D Map screen, then Add to Trip. You can save up to 200 multi-stop trips, each with up to 14 destination points. Step One: Start your Multi-stop Trip a.
iCN 550 User Manual Step Two: Select the Country of your Destination Point a. If the destination point is in a different country to the previous destination point, tap Change country or Change country or state. The Select country screen will display. b. Select a country from the list. The Destination screen will display. Step Three: Select the State of your Destination Point a. Select a state from the list. The Destination screen will display.
iCN 550 User Manual Step Four: Find the Town or City of your Destination Point a. From the Destination screen, tap Find town/city. The Keyboard screen will display. b. Use the Keyboard screen to find the town or city of your destination. For information on using the Keyboard screen, see pages 15-16. The Destination screen will display. Step Five: Find the Street of your Destination Point a. From the Destination screen, tap Find street. The Keyboard screen will display. b.
iCN 550 User Manual Step Six: Find the House Number of your Destination Point a. From the Destination screen, tap Enter house number. The Keyboard screen will display. Note: If Enter house number option is not displayed, house numbers are not available for your selected street. Select Go to center of street to display the Preview screen. Go to step c. b. Use the Keyboard screen to find the house number of your destination point. For information on using the Keyboard screen, see pages 15-16.
iCN 550 User Manual d. Complete one of the following: Note: Destination points added, updated or deleted after a multi-stop trip has commenced will not affect the current route. If you want to ... Then ... add another destination point Note: Destination points added after a multi-stop trip has commenced will not be included in the current route. i tap Add. The Add to Trip screen will display. ii tap Address. The Destination screen will display.
iCN 550 User Manual 7. Viewing your Route Once a route has been calculated, you can view it in several ways. Press to cycle through the screens. 2D Map Screen The 2D Map screen is always oriented North and shows your current position (if a GPS fix is active) and surrounding street names. If a route has been calculated, the route and turns are highlighted. You can plan a route from the 2D Map screen. See page 23 for further details.
iCN 550 User Manual 3D Map Screen The 3D Map screen displays when a route is calculated, oriented to the traveling direction with an adjustable horizon. It is not possible to plan a route directly from this screen. To view the 3D Map screen when a route has been calculated, press • to cycle through the screens. To adjust the viewing angle, press the 4-way toggle up or down. T • To display a smaller area in greater detail, press +. • To display a larger area in less detail, press -.
iCN 550 User Manual Next Turn Screen The Next Turn screen displays information that you need for the next turn, the direction of the turn and the distance to the turn. A route must have been calculated for this screen to be able to display. Access to this screen is controlled by the Display preferences screen. See page 44. To view the Next Turn screen when a route has been calculated, press to cycle through the screens. Map of the next turn The next instruction Additional information can display here.
iCN 550 User Manual Route Information Screen The Route Information screen provides information about your current route and lets you skip a trip destination point or cancel a route. The screen is only available from the Main Menu when you are navigating a route: Main Menu Route Information Show Route Tap Show Route to display your entire route on the 2D Map screen. Instruction List Tap Instruction list to display the Instruction List screen.
iCN 550 User Manual 8. The 2D Map Screen Pop-up Menu The Pop-up menu allows you to access navigational functions from the 2D Map screen. To display the Pop-up menu, complete the following: 1. From the Main Menu, tap Map. The 2D Map screen will display. • Move around the 2D Map screen using the 4-way toggle or stylus. • To display a smaller area in greater detail, press +. • To display a larger area in less detail, press -. 2. Tap the Map screen or press the 4-way toggle button to display the cross-hairs.
iCN 550 User Manual 9. Avoiding an Area You can calculate a route that avoids a specified area on the map. For example, you may want to avoid an area that frequently experiences traffic problems. Up to ten Avoid Areas can be added. Avoid Areas are displayed as shaded areas. If no alternative route around an Avoid Area exists, you will be routed through an Avoid Area. Adding an Avoid Area 1. From the Main Menu screen, tap Map. The 2D Map screen will display. 2.
iCN 550 User Manual 10. Route Demonstrator The Route Demonstrator allows you to: • Preview a route. • Plan and view a route without a GPS fix, such as when you are inside a building. Step One: Activate Route Demonstrator 1. From the Main Menu screen, tap Preferences. 2. From the Preferences screen, tap Routing. The Routing screen will display. 3. Press twice. 4. Select the Demonstrate Route check box. 5. Tap Save. The Main Menu screen will display.
iCN 550 User Manual To Disable Route Demonstrator 1. Press to display the Main Menu screen. 2. From the Main Menu screen, tap Preferences. 3. From the Preferences screen, tap Routing. The Routing screen will display. 4. Press twice. 5. Clear the Demonstrate Route check box. 6. Tap Save. The Route Demonstrator will be disabled. The Main Menu screen will display.
iCN 550 User Manual 11. Favorites and My Home You can save up to 200 destinations as Favorites, one of which can be saved as My Home. My Home can be any designated Favorite, but we recommend that it is your home or other common destination. You can save a Favorite from the Preview screen after searching for an address, or from the Pop-up Menu on the 2D Map screen. Saving a Favorite 1.
iCN 550 User Manual 4. Complete one of the following: • To save as My Home, tap Save as My Home. The Favorite is saved as My Home. The Go To screen will display. • To save as a favorite, tap Save as Favorite. The Favorite is saved. The Go To screen will display. Saving a Favorite from the 2D Map Screen 1. From the Main Menu, select Map. The 2D Map screen will display. 2. Tap the Map screen or press the 4-way toggle button to display the cross-hairs. 3. Position the intersection of the cross-hairs.
iCN 550 User Manual 6. To change the name of the Favorite, select the Name box. The Enter text screen will display. • To select a character, tap the character. • To delete a character, press ESC or tap <<; hold ESC to delete the line. • To display the number/symbol Enter text screen, tap 123. • To display the alternate Enter text screen, press +, or tap Alt. • To display the alphabet Enter text screen, press -, or tap ABC • After you have entered a name for the Favorite, tap Enter.
iCN 550 User Manual 4. Tap the Name box. The Enter text screen will display. • To select a character, tap the character. • To delete a character, press ESC or tap <<; hold ESC to delete the line. • To display the number/symbol Enter text screen, tap 123. • To display the alternate Enter text screen, press +, or tap Alt. • To display the alphabet Enter text screen, press -, or tap ABC • After you have entered a name for the Favorite, tap Save. The New Favorite screen will display. 5.
iCN 550 User Manual Navigating to a Favorite 1. From the Main Menu, tap Go To. 2. From the Go To screen, tap Favorites. The Favorite screen will display. 3. Select a Favorite. The Preview Favorite screen will display. 4. Tap Go. The route is calculated and displayed on the 3D Map screen. Navigating to My Home 1. From the Main Menu, tap Go To. 2. From the Go To screen, tap My Home. The route is calculated and displayed on the 3D Map screen.
iCN 550 User Manual 12. Preferences You can modify the following preferences to suit your needs. Screen Brightness 1. Press and hold either the + or - button to display the Brightness scale. 2. To increase screen brightness, press +; to decrease screen brightness, press -. The Brightness scale comprises ten rectangular boxes in a row. As screen brightness is increased, the first seven boxes progressively turn from gray to green; the last three turn red.
iCN 550 User Manual If you want to... Then... change the Preference for freeways move the Preference for freeways slider towards Less often to use roads other than freeways where possible when calculating a route. move the slider towards More often to use freeways where possible when calculating a route. change the Preference for urban roads move the Preference for urban roads slider towards Less often to use roads other than urban roads where possible when calculating a route.
iCN 550 User Manual If you want to... Then... enable Track Recording (only to be used if required by Navman Customer Support) contact Navman Customer Support, as we recommend this feature be used only under the supervision of a Navman technician. 4. Tap Save. The Main Menu screen will display. Map Preferences — Display Settings 1. From the Main Menu, tap Preferences. 2. From the Preferences screen, tap Maps. 3. From the Maps screen, tap Display. The first of two Display screens will display.
iCN 550 User Manual If you want to... Then... turn on the keypad backlight when the iCN is using external power select the Night Keypad Lighting check box. Note: This option is only available when Map colors is set to Night. display topographical information on the 2D Map and 3D Map screens select the Topographic display check box. display grid lines on the 2D Map and 3D Map screens select the Display Map Grid check box.
iCN 550 User Manual Alerts Preferences — Active POIs The Active POI settings allow you to set warning chimes and visual warnings for custom POIs that will activate within a chosen radius of your location. For example, a warning chime will sound or a visual warning will display when an active POI is within 150 ft of, but not necessarily on, your route. Note: Custom POIs must first be installed on your iCN using Smart Desktop before they can be set as active POIs.
iCN 550 User Manual Alerts Preferences - Speed and GPS Signals The Safety settings allow you to set safety-related warnings. 1. From the Preferences menu, tap Safety Alerts. The Safety Alerts screen will display. 2. On the Safety Alerts screen, tap Safety. The Safety screen will display. 3. Complete the following: If you want to... Then...
iCN 550 User Manual My Data Preferences - My Points of Interest (My POI) Custom Points of Interest (POIs) are installed from the Smart Desktop POI Editor (see pages 61-63), and listed on the My POIs screen. 1. From the Main Menu, tap Preferences. 2. From the Preferences screen, tap My Data. 3. From the My Data screen, tap My POI. The My POI screen will display. 4. To select a POI file, select the POI check box. Note: tthere here may be more than one page of POI types.
iCN 550 User Manual GPS Status Signals are transmitted by Global Positioning System (GPS) satellites orbiting the Earth. The Satellite Signal Strengths screen provides a visual representation of the information being received. Latitude and longitude are displayed, along with a north-pointing compass, the heading in degrees and ground speed. The strength of each satellite is displayed on a bar chart. From the Main Menu screen, select Preferences More Preferences GPS st status.
iCN 550 User Manual Measurement Preferences 1. From the Main Menu screen, tap Preferences. The Preferences screen will display. 2. From the Preferences screen, tap More Preferences. The second Preferences screen will display. 3. On the second Preferences screen, select Measurements. The Measurements screen will display. 4. Complete the following: If you want to... Then... change the Position format select either the Decimal degrees or the Degrees, minutes, seconds option.
iCN 550 User Manual Hardware Preferences - Screen 1. From the Main Menu screen, tap Preferences. The Preferences screen will display. 2. From the Preferences screen, tap More Preferences. The second Preferences screen will display. 3. On the second Preferences screen, tap Hardware. The Hardware screen will display 4. From the Hardware screen, tap Screen. The Screen screen will display. 5. Complete the following: If you want to... Then... align the touch screen tap Align and follow the prompts.
iCN 550 User Manual Hardware Preferences - Volume 1. From the Main Menu screen, tap Preferences. The Preferences screen will display. 2. From the Preferences screen, tap More Preferences. The second Preferences screen will display. 3. On the second Preferences screen, tap Hardware. The Hardware screen will display. 4. From the Hardware screen, tap Volume. The Volume screen will display. 5.
iCN 550 User Manual Hardware Preferences - Power Status 1. From the Main Menu screen, tap Preferences. The Preferences screen will display. 2. From the Preferences screen, tap More Preferences. The second Preferences screen will display. 3. On the second Preferences screen, tap Hardware. The Hardware screen will display 4. From the Hardware screen, tap Power Status. The Power Status screen will display. 5. Press to return to the Main Menu screen. Hardware Preferences - Power Options 1.
iCN 550 User Manual 5. Complete the following: If you want to... Then... change the time to elapse before entering suspended state, when connected to an external power source i select the Go to Power Saving Mode if not used for check box under External Power. change the time to elapse before entering suspended state, when using battery power i select the Go to Power Saving Mode if not used for check box under Internal Backup Battery.
iCN 550 User Manual 13. Smart Desktop Smart Desktop is used to install maps to your iCN, obtain software updates, manage Custom Points of Interest (POIs) and install Basemaps. Microsoft® ActiveSync® Microsoft ActiveSync is used to establish a connection between your iCN and your computer. ActiveSync 3.7.1 will be installed on your computer (if it is not already installed) as part of the installation of Smart Desktop.
iCN 550 User Manual 5. If prompted to connect your iCN to your computer, complete the following: • Plug the large end of the USB cable directly into a USB port on your computer (not a USB hub); plug the small end into the USB Socket on the side of your iCN. Tip: Where possible, plug the USB cable into a USB port at the back of your computer. • Plug the small end of the AC Power Pack cable into the Power Socket on the bottom of your iCN; plug the other end into the mains. • Press . The iCN will turn on.
iCN 550 User Manual 14. Updating your iCN Updating your Version of Smart We recommended that you regularly use Smart Desktop to check the Navman website for Smart software updates: 1. If you connect to the Internet via a dial-up connection, connect to the Internet now. 2. Open Smart Desktop: Start Programs Navman Smart Desktop 2005 Release 2 for iCN550 3. On the Setup menu, select Update software, then Check for updates on the web.
iCN 550 User Manual 15. Installing Maps Using Smart Desktop NOTE: Your iCN 550 comes with preinstalled maps of the United States and Canada. If you have purchased a software or map upgrade, follow the instructions in your Upgrade Guide to install and activate your new software or maps. Installing and Activating Maps on your iCN 1. Open Smart Desktop, if it is not already open: Start Programs Navman Smart Desktop Rel Release ease 2 for iCN550 2.
iCN 550 User Manual 5. Click the map to install to your iCN. The map will change colour to indicate it has been selected (the default colour for selected maps is dark green). The map is now listed in the Selected section of the Desktop Selected Maps tab. The selected map is displayed in dark green. 6. Click the Add to button to install all maps listed in the Selected section of the Desktop Selected Maps tab to your iCN. Smart Desktop will install the selected map or maps to your iCN or iCN memory card.
iCN 550 User Manual 16. Smart Desktop Advanced Features This section details advanced features of Smart Desktop. If you have not installed Smart Desktop, see pages 55-56. To Find a City or Town 1. From the Map menu, click Find City. The Find City window will open. 2. Type the name of the city or town in the City Name field. The list of available cities will reduce to match your search. 3. Double-click the name of the city or town.
iCN 550 User Manual Map Layers To conserve space on your iCN and memory card, you can choose map layers to install. The layers you can choose from are: • Points of Interest (POIs) • Bodies of water and parks • Land contours (topography). To access the Map Layers section: Desktop tab Settings Layers. Select or clear each checkbox to indicate the layers to install for each map.
iCN 550 User Manual 2. Add a POI to the POI File. • On the POI Editor window Edit menu, click New. The POI Details window will open. • Type a description for the POI in the Description box. • On the Degrees, Minutes, Seconds tab, type or select the degree, minute and second of the POI latitude in the Latitude boxes. • On the Degrees, Minutes, Seconds tab, type or select the degree, minute and second of the POI longitude in the Longitude boxes. • To save the POI, click OK. 3.
iCN 550 User Manual 3. Modify the POI settings as required: If you want to... Then... activate the POI select the Active check box. Note: If you do not activate the POI, you will be able to configure only the POI Visibility Level and Icon File settings. enable a visual warning when the POI is in close proximity select the Visual Alert check box. enable a warning chime when the POI is in close proximity select the Audio Alert check box.
iCN 550 User Manual Backups You can save backups of all iCN Preferences and Favorites to your computer. To Back up your Preferences, Favorites and My Home 1. On the Smart Desktop File menu, click Backup. The Backup window will display. 2. Click New Backup. The New Backup window will display. 3. Click OK. The New Backup window will close. The backup will be listed on the Backup window. 4. Close the Backup window. To Delete a Backup 1. On the Smart Desktop File menu, click Backup.
iCN 550 User Manual 17. Accessories You can purchase separately almost all items that came with your iCN, including additional mounting kits and in-vehicle power adaptors. Visit your retailer or your regional Navman website for more information. See page 74 for web addresses.
iCN 550 User Manual Appendix: Street Types Country Street Type Abbreviation Canada ABBEY ACRES ALLEE ALLEY AUTOROUTE AVENUE (English) AVENUE (French) ABBEY ACRES ALLEE ALLEY AUT AVE AV BAY BEACH BEND BOULEVARD (English) BOULEVARD (French) BY-PASS BYWAY BAT BEACH BEND BLVD BOUL BYPASS BYWAY CAMPUS CAPE CARRÉ CARREFOUR CENTER (English) CENTER (French) CERCLE CHASE CHEMIN CIRCLE CIRCUIT CLOSE COMMON CONCESSION CORNERS COTE COUR COURT COVE CRESCENT CROISSANT CROSSING CUL-DE-SAC CAMPUS CAPE CAR CARREF
iCN 550 User Manual Country Street Type Abbreviation Canada (continued) EXPRESSWAY EXTENSION EXPY EXTEN FARM FIELD FOREST FREEWAY FRONT FARM FIELD FOREST FWY FRONT GARDENS GATE GLADE GLEN GREEN GROUNDS GROVE GDNS GATE GLADE GLEN GREEN GRNDS GROVE HARBOUR HEIGHTS HIGHLANDS HIGHWAY HILL HOLLOW HARBR HTS HGHLDS HWY HILL HOLLOW ÎLE IMPASSE ISLAND iLE IMP ISLAND KEY KNOLL KEY KNOLL LANDING LANE LIMITS LINE LINK LOOKOUT LOOP LANDNG LN LMTS LINE LINK LKOUT LOOP MALL MANOR MAZE MEADOW MEWS MONTEE
iCN 550 User Manual Country Street Type Abbreviation Canada (continued) PARK PARKWAY PASSAGE PATH PATHWAY PINES PLACE (English) PLACE (French) PLATEAU PLAZA POINT PORT PRIVATE PROMENADE PK PKY PASS PATH PTWAY PINES PL PLACE PLAT PLAZA PT PORT PVT PROM QUAY QUAY RANG RANGE RIDGE RISE ROAD ROND POINT ROUTE ROW RUE RUELLE RUN RANG RG RIDGE RISE RD RDPT RTE ROW RUE RLE RUN SENTIER SQUARE STREET SUBDIVISION SENT SQ ST - ‘ SUBDIV TERRACE TERASSE THICKET TOWERS TOWNLINE TRAIL TURNABOUT TERR TSSE THICK
iCN 550 User Manual Country Street Type Abbreviation United States of America ALLEY ANNEX ARCADE AVENUE ALY ANX ARC AVE BAYOO BEACH BEND BLUFF BLUFFS BOTTOM BOULEVARD BRANCH BRIDGE BROOK BROOKS BURG BURGS BYPASS BYU BCH BND BLF BLFS BTM BLVD BR BRG BRK BRKS BG BGS BYP CAMP CANYON CAPE CAUSEWAY CENTER CENTERS CIRCLE CIRCLES CLIFF CLIFFS CLUB COMMON CORNER CORNERS COURSE COURT COURTS COVE COVES CREEK CRESCENT CREST CROSSING CROSSROAD CURVE CP CYN CPE CSWY CTR CTRS CIR CIRS CLF CLFS CLB CMN COR CORS C
iCN 550 User Manual Country Street Type Abbreviation United States of America (continued) ESTATE ESTATES EXPRESSWAY EXTENSION EXTENSIONS EST ESTS EXPY EXT EXTS FALLS FERRY FIELD FIELDS FLATS FORD FORDS FOREST FORGE FORGES FORK FORKS FORT FREEWAY FLS FRY FLD FLDS FLTS FRD FRDS FRST FRG FRGS FRK FRKS FT FWY GARDEN GARDENS GATEWAY GLEN GLENS GREEN GREENS GROVE GROVES GDN GDNS GTWY GLN GLNS GRN GRNS GRV GRVS HARBOR HARBORS HAVEN HEIGHTS HIGHWAY HILL HILLS HOLLOW HOUSE HBR HBRS HVN HTS HWY HL HLS HOLW
iCN 550 User Manual Country Street Type Abbreviation United States of America (continued) LAKE LAKES LANDING LANE LIGHT LIGHTS LOAF LOCK LOCKS LODGE LOOP LK LKS LNDG LN LGT LGTS LF LCK LCKS LDG LOOP MANOR MANORS MARKET MEADOW MEADOWS MILL MILLS MISSION Freeway MOUNT MOUNTAIN MOUNTAINS MNR MNRS MKT MDW MDWS ML MLS MSN MTWY MT MTN MTNS NECK NCK ORCHARD OVAL OVERPASS ORCH OVAL OPAS PARK PARKS PARKWAY PARKWAYS PASS PASSAGE PATH PIKE PINE PINES PLACE PLAIN PLAINS PLAZA POINT POINTS PORT PORTS PRAIRIE
iCN 550 User Manual Country Street Type Abbreviation United States of America (continued) RANCH RAPID RAPIDS REST RIDGE RIDGES RIVER ROAD ROADS ROUTE ROW RUE RUN RNCH RPD RPDS RST RDG RDGS RIV RD RDS RTE ROW RUE RUN SHOAL SHOALS SHORE SHORES SKYWAY SPRING SPRINGS SPUR SPURS SQUARE SQUARES STATION STRAVENUE STREAM STREET STREETS SUMMIT SHL SHLS SHR SHRS SKWY SPG SPGS SPUR SPUR SQ SQS STA STRA STRM ST STS SMT TERRACE THROUGHWAY TRACE TRACK TRAFFICWAY TRAIL TUNNEL TURNPIKE TER TRWY TRCE TRAK TRFY TRL
iCN 550 User Manual Country Street Type Abbreviation United States of America (continued) VILLE VISTA VL VIS WALK WALKS WALL WAY WAYS WELL WELLS WALK WALK WALL WAY WAYS WL WLS 73
iCN 550 User Manual Support Information Support for Australia: Support for Europe: Navman Australia Pty. Ltd PO Box 479 Gladesville, NSW 2111 Australia Navman Europe Limited 4G Gatwick House Peeks Brook Lane Horley, Surrey RH6 9ST United Kingdom Support: support.navman.com Website: www.navman.com Support: support.navman.com Website: www.navman-europe.com Support for New Zealand: Support for US and Canada: Navman NZ Ltd PO Box. 68-155 Newton Auckland New Zealand Navman USA, Inc.
