INTRODUCTION IMPORTANT NOTES Thank you for buying this product. Please read through these operating instructions, so you will know to operate your equipment properly. After you finished reading the instructions manual, put it away in a safe place for future reference. WARNING To prevent fire or shock hazard, do not expose this appliance to rain or moisture. To avoid electrical shock, do not open the cabinet, refer servicing to qualified personnel only.
LOCATION OF CONTROLS -2-
FEATURES AND CONTROLS 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 30. 1. HANDLE 2. CD COMPARTMENT 3. FUNCTION SWITCH 4. BATTERY COMPARTMENT 5. STANDBY INDICATOR 6. LED DISPLAY 7. CD STOP BUTTON 8. FM STEREO INDICATOR 9. CD PLAY/PAUSE BUTTON 10. SPEAKER JACK (L&R) 11. BAND SELECTOR 12. STANDBY BUTTON 13. X-BASS BUTTON 14. VOLUME CONTROL 15. AUX IN JACK 16. CD PROGRAM BUTTON 17. CD SKIP/SEARCH NEXT BUTTON 18. CD SKIP/SEARCH BACK BUTTON 31. 32. 33. 34.
CASSETTE OPERATION PLAYBACK OF CASSETTE Be sure to tighten any slack tape in the cassette before use, using either a pencil or a ballpoint pen, simply insert the pen or pencil into the center of spool and rotate to remove slacks. Depress the STOP/EJECT button to open the cassette door.
PROTECTING RECORDING Normally, anything recorded on the tape is automatically erased when new recording is made. It is possible to protect your recording from accidental erasure by removing the tabs found on the rear of the cassette. When the cassette is held with the recorded side upper-most and exposed tape facing the front, the protective tab will be found on the left rear of the cassette. All pre-recorded cassette are protected in this way to prevent accidental erasure of the commercial recording.
Selecting a Different Track during Play 1. Press CD SKIP/SEARCH NEXT/BACK button on the unit continuously until the desired track number appears in the display. 2. Playback starts from the desired track. (Press CD PLAY/PAUSE button to start playback in stop mode) Starting Again With the Track That Is Currently Playing 1. Press CD SKIP/SEARCH BACK button once. 2. The playback will start again from the beginning of the track. Stopping Play 1. Press CD STOP button if you wish to stop play.
SPECIFICATIONS GENERAL Power Requirement …………………………………………AC 110/220V ~ 60/50Hz DC 12V UM-1 x 8 PCS Power consumption….…………………………………..….AC 17 Watts Weight …………………………………………………………Approx. 4.0kg Dimensions…………………………………………Approx. 455mm (W) x 220mm (H) x 240mm (D) Operation temperature ……………………………………. +5° C - + 35 °C RECEIVER SECTION Receiving Bands …………………………………………….AM / FM Tuning Range …………………….. ………………………..AM 530 - 1710 KHz FM 88 - 108 MHz COMPACT DISC SECTION Optical Pickup ……………………………………………....
