Lower Feeder Unit (LFU)
133
Kit Contents
„ Lower feeder unit (LFU)
„ Universal media tray (500 sheets)
„ One small metal bracket with thumb-
screw (attached to the LFU)
„ Two plastic side covers (one left and
one right)
5"
There may be other pieces shipped
with the
LFU
; however, they are not
required for this procedure.
Installation
WARNING!
Your printer weighs approximately 112 lbs (51 kg) with consumables. Be
sure to have help when lifting and moving it.
ACHTUNG! Das Gewicht dieses Druckers beträgt mit
Verbrauchsmaterial ca. 51 kg. Bitte versuchen Sie niemals, den Drucker
alleine anzuheben oder zu transportieren.
Attention
Never lift a printer with the fuser oil bottle installed. If other
consumables are installed, be sure to keep the printer level when
moving it to prevent accidental spills.
