Internal IDE Hard Disk Drive148
b Gently press the ribbon cable connector down until it’s fully seated.
Attention
Make sure that the connectors on the ribbon cable and the controller
board are properly aligned. Damage to the controller board could
result if the pins are misaligned.
c Insert the SCSI interface card connector into its opening in the inter-
face panel.
d Secure the SCSI interface card to the interface panel with the two
larger screws in the kit.
5
Reinstall the controller board.
Gently slide the controller board into the printer’s tracks until it’s fully
seated, and then tighten the controller board’s two screws.
6
Reconnect all interface cables.
7
Reconnect the power cord and turn on the printer.
5"
In compliance with UL guidelines, “The appliance inlet is consid-
ered to be the main disconnect device.”
8
Print a startup page.
Check that the startup page lists the interface (SCSI) just installed under
“Options.”
Using a SCSI Interface
5"
Installing a SCSI interface allows the attachment of external SCSI
storage devices, such as hard drives, and Jaz and Zip drives. Install-
ing the SCSI interface kit will not allow you to print via SCSI.
Internal IDE Hard Disk Drive
Attention
Make sure that the printer and all accessories are turned off before
installing accessories involving the controller board.
One optional internal IDE hard disk is supported.
