Requirements180
Requirements
Space Requirements
The illustration below shows the amount of space required for operating the
printer, replacing supplies, and removing media jams.
5"
Allow enough space around the printer to allow adequate ventilation
and easy servicing. For best output quality and longest consumables
life, install the printer on a hard, flat, level (within 1.5°) surface.
Top View—Basic Model
Top View with Duplex Unit
015mati.eps
28 inches
(70 cm)
8 inches
(20 cm)
20 inches
(50 cm)
Front
4 inches
(10 cm)
015mati.eps
28 inches
(70 cm)
20 inches
(50 cm)
Front
4 inches
(10 cm)
(70 cm)
28 inches
