Engine and Controller Specifications186
Print Speed—Autoduplex
The following table defines the maximum print speed in pages per minute
(monochrome ppm) or in images per minute (4-color ipm).
General
Page size Mono-
chrome
ppm
2-Color
ipm
3-Color
ipm
4-Color
ipm
A4
12 4 4 6
Letter
12 4 4 6
Legal
6321.5
A3
6321.5
Ledger
6321.5
Oversize*
6321.5
Film
N/A N/A N/A N/A
Label
N/A N/A N/A N/A
Thick
2.4 2.4 (2**) 2 1.5
* 12" x 18” (304.8 x 457.2 mm) and 13” x 18” (330.2 x 457.2 mm) media
cannot be autoduplexed.
** Reduced 2-color page rate for Black/Yellow combination only.
Printer type
Desktop, non-impact, 4-color printer
Print method Scanner:
Semiconductor laser with rotating mirror
Recorder:
Black writing electrophotographic
Process:
Cyan, magenta, yellow, and black dry toner
image transfer to print media
Fuser:
Heated rollers
Resolution Standard:
1200x1200 dpi
You may also need additional memory (DIMMs) for the
following:
„ To print complex graphics or complex PostScript
documents
„ For increased collation performance
„ For increased spooling performance
