Engine and Controller Specifications188
Fonts PostScript—137 resident PostScript fonts that can be
scaled from 4 points upward and rotated to any angle in 1°
increments; all typefaces have multilingual character sets
HP PCL 5e, 5c—45 scalable and 9 bitmap fonts
PCL 6
PCL XL—45 scalable and 9 bitmap typefaces
HP-GL—40 resident HP-GL symbol sets
Type 1 / Type 3 Support—Support for Type 1 and Type 3
host-resident downloadable PostScript fonts
TrueType—Support for Type 42 (PostScript format)
host-resident downloadable TrueType fonts, support for
TrueType fonts in PCL
Kanji fonts Hard disk—MINOLTA-QMS Kanji Internal IDE Hard Disk
Drive with two Morisawa fonts
Standard
interfaces
CrownNet Ethernet—10BaseT/100BaseTX
Parallel—Centronics/IEEE 1284 bidirectional
Optional
interfaces
Network interface—Support for one optional network
interface (CrownNet for Ethernet, supporting EtherTalk,
LAN Manager/LAN Server, Netware, and TCP/IP; Crown-
Net for Token-Ring, supporting LAN Manager/LAN Server,
NetWare, and TCP/IP; or Crown for DECnet-TCP/IP)
SCSI interface—Support for up to 3 external SCSI hard
disks (up to 2 GB), Jaz drives or Zip drives
RAM Type: PC-100 Compliant SDRAM DIMMs
GN model base system RAM: 192 MB
Total RAM: Upgradable to 384 MB (through 3 DIMM
connectors)
Optional RAM 32, 64, and 128 MB DIMMs
System
software
Softloadable; stored in Flash ROM
Internal IDE
hard disk
GN model: Optional, up to 2.2 GB
5"
For information about hard disks recommended for
your printer, see the magicolor 6110 Answer Base
through the Internet at www.minolta-qms.com/
support/, or contact Support. Refer to the
Service &
Support Guide
for more information.
