Engine and Controller Specifications190
Current
Environmental
Mode Average Maximum
Operation
Standby
Power saver mode
5 amperes
1.7 amperes
11 amperes
11 amperes
0.40 amp-
eres
Noise level Printing:
Less than 55 dB (A)
Standby:
Less than 41 dB (A)
Relative
humidity
Operating:
20-80% RH (noncondensing)
Transportation/Storage:
10–90% RH (non-
condensing)
Temperature
range
Operating:
50-90.5° F (10-32.5° C)
Transportation/Storage:
32-95° F (0-35° C)
Altitude Operating:
0-8202 ft (0-2500 m)
Inclination Operating:
1.5° or less slant at any point around the
machine
80
60
40
70
50
30
20
0
10
10
20
30
17.5
27
32.5
Optimal Operating Range
Acceptable Operating Range
Ambient Humidity (%RH)
50
63.5
68
80.6
86
95.0
Cº
Fº
Ambient Temperature
