Replacing the Cleaning Roller
23
Replacing the Cleaning Roller
WARNING!
The fuser unit can become extremely hot and cause severe
burns. Make sure the unit is cool before handling it.
ACHTUNG! Die Fixiereinheit kann sehr heiß werden, so daß
Verbrennungsgefahr besteht. Bitte lassen Sie die Fixiereinheit einige
Zeit abühlen, bevor Sie diese berühren.
Attention
When the top cover is opened, the fuser unit temperature drops
gradually (one hour wait time).
Do not replace the cleaning roller until you are sure that the fuser unit
has cooled down.
How do I replace the cleaning roller?
1
Turn off the printer.
2
Open the top cover of the
printer.
Attention
If you have installed a duplex unit, it must be opened before the
printer’s top cover.
1
2a
2b
