Printing Area
35
Imageable (Printable) Area
Nonprintable
area
For nonguaranteed area,
add another
Plain paper, front side, all edges
(media up to but not including 12” x
18” (304.8 mm x 457.2 mm)
0.197" (5 mm) 0.078" (2 mm)
Duplex (back side, leading edge)* 0.078" (2 mm)
Duplex, front side* 0.118" (3 mm)
Thick stock, labels, transparencies,
front side only, all edges
0.197" (5 mm)
Envelopes Varies
Side margins for media 12” x 18”
(304.8 mm x 457.2 mm) and larger
0.393” (10 mm) N/A
*An optional duplex unit can be added to all models that have a lower feeder unit
attached. Only plain paper can be duplexed.
Guaranteed area
Nonprintable area
Nonguaranteed area
Leading edge
Trailing edge
Nonguaranteed area
Nonprintable area
Media feed direction
