Cleaning the Printer
63
8
Secure its lock levers.
9
Close the printer’s
top cover.
5"
If you have a duplex
unit installed, close
its top cover.
10
Close the printer’s front
cover.
Cleaning the Laser Lens
It’s necessary to clean the laser lens only when you find vertical white or
light-color streaking in all primary colors on your printouts.
5"
A dry cotton cloth or dry cotton swab is required for this procedure.
1
Open the printer’s front cover.
2
Remove the four toner cartridges.
3
Open the laser lens cover.
4
Release the two tabs on the front edge of the lens cover and rotate the
hinged lens cover toward the rear of the printer.
b
a
c
