Clearing Media Jams76
Inner Jams, Outer and Drum Jams
WARNING!
The fuser unit is hot! Do not remove a jam in this area until the
fuser unit cools.
ACHTUNG! Die Fixiereinheit wird sehr heiß! Bitte achten Sie darauf, daß
sie diese einige Zeit abkühlen lassen, bevor Sie einen Papierstau
beseitigen.
5"
Media that hasn’t fully passed through the fuser contains unfused
toner that can dirty your hands, clothes, or other items. If you get toner
on your hands, wash them in cool water and neutral detergent. If you
get toner on your clothes, lightly dust them off as much as possible. If
toner remains on your clothes, use cool, not hot water, to rinse the
toner off, provided your clothing is washable.
1
Open the rear cover of the
printer.
2
Remove the jammed media
by pulling it toward you.
3
Close the printer’s rear cover.
