Clearing Media Jams
77
4
If there still is a jam
message and you have
a duplex unit installed,
open the duplex unit’s
top cover.
Attention
If you have installed a duplex unit, it must be opened before the
printer’s top cover.
If not, skip to step 5.
5
Open the printer’s top cover.
Pull the top latch to release the top cover.
5"
These illustrations show the printer without the duplex unit
attached; however, the instructions are the same for all models.
6
Remove the jammed media
by pulling it toward you.
1
2a
2b
