Clearing Media Jams78
7
If you cannot reach the
media from the top of
the fuser or the media
will not come out easily,
open the fuser roller
pressure release levers
(one at each end of
the fuser).
8
Remove the jammed
media by pulling it from
the bottom of the fuser
(through the printer’s
rear cover), not from
the top of the fuser.
This prevents any
unfused toner from
dirtying the fuser
rollers.
Attention
Be careful not to touch the transfer drum while removing
jammed media.
9
Close the fuser roller pressure release levers (one at each end of the
fuser).
10
Close the top cover of the printer.
11
Close the duplex unit’s top cover, if necessary.
12
Close the rear cover of the printer.
