MultiSync LCD1810X User’s Manual CN912B-2/LCD1810X/78135322 1 00.5.
CN912B-2/LCD1810X/78135322 2 00.5.
Declaration of the Manufacture We hereby certify that the colour monitors MultiSync LCD1810X (LH-18S01) MultiSync LCD1810X (LH-18S01-BK) are in compliance with Council Directive 73/23/EEC: - EN 60950 Council Directive 89/336/EEC: - EN 55022 - EN 61000-3-2 - EN 61000-3-3 - EN 55024 and marked with NEC Home Electronics, LTD. 686-1, Nishioi Oi-Machi Ashigarakami-gun Kanagawa 258-8533, Japan CN912B-2/LCD1810X/78135322 3 00.5.
Safety Instruction WARNING TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED. REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM WALL SOCKET.
For the Customer to use in U.S.A or Canada. Canadian Department of Communications Compliance Statement DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouiller du Canada. C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to C.S.A. C22.2 #950.
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult your dealer or an experienced radio/TV technician for help.
TCO'95 LH-18S01-BK Congratulations! You have just purchased a TCO'95 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also, to the further development of environmentally adapted electronics products.
computers. The labelling scheme was developed as a joint effort by the TCO (The Swedish Confederation of Professional Employees), Naturskyddsforeningen (The Swedish Society for Nature Conservation) and NUTEK (The National Board for Industrial and Technical Development in Sweden). The requirements cover a wide range of issues: environment, ergonomics, usability, emission of electrical and magnetic fields, energy consumption and electrical and fire safety.
TCO'95 is a co-operative project between TCO (The Swedish Confederation of Professional Employees), Naturskyddsforeningen (The Swedish Society for Nature Conservation) and NUTEK (The National Board for Industrial and Technical Development in Sweden). Environmental Requirements Brominated flame retardants Brominated flame retardants are present in printed circuit boards, cables, wires, casings and housings. In turn, they delay the spread of fire.
Mercury** Mercury is sometimes found in batteries, relays and switches. Mercury damages the nervous system and is toxic in high doses. TCO'95 requirement states that batteries may not contain more than 25 ppm (parts per million) of mercury. It also demands that no mercury is present in any of the electrical or electronics components concerned with the display unit.
TCO'99 LH-18S01 Congratulations! You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
Svenska Naturskyddsforeningen (The Swedish Society for Nature Conservation) and Statens Energimyndighet (The Swedish National Energy Administration). Approval requirements cover a wide range of issues: environment, ergonomics, usability, emission of electric and magnetic fields, energy consumption and electrical and fire safety.
Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs.
CFCs (freons) The relevant TCO'99 requirement states that neither CFCs nor HCFCs may be used during the manufacture and assembly of the product. CFCs (freons) are sometimes used for washing printed circuit boards. CFCs break down ozone and thereby damage the ozone layer in the stratosphere, causing increased reception on earth of ultraviolet light with e.g. increased risks of skin cancer (malignant melanoma) as a consequence.
CN912B-2/LCD1810X/78135322 15 00.5.
E-1 Introduction to the NEC MultiSync LCD1810X English Introduction to the NEC MultiSync LCD1810X Congratulations on your purchase of the NEC MultiSync LCD1810X true colour monitor! Deutsch ambix Technology Français Dual input technology allowing both analog and digital inputs through one connector (DVI-I) as well as additional legacy analog support through a traditional 15-pin VGA connector.
Introduction to the NEC MultiSync LCD1810X E-2 NuCycle Plastic Wide Viewing Angle Technology Allows the user to be able to see the monitor from any angle(160 degrees) from any orientation – Portrait or Landscape. Provides full 160˚ viewing angles either up, down, left or right. Provides the ideal solution for environments requiring superior image quality but with size and weight limitations.
E-3 Introduction to the NEC MultiSync LCD1810X English Pivoting Stand Deutsch Allows users to adjust the monitor to the orientation that best fits their application, either Landscape orientation for wide documents, or portrait orientation for the ability to preview a full page on one screen at one time. The Portrait orientation is also perfect for full screen video conferencing.
Contents of Package E-4 English Contents of Package Your new MultiSync LCD monitor box should contain the following: Deutsch Video Signal Cable (15-pin mini D-SUB to DVI) Français Video Signal Cable (DVI-D to DVI-D cable) – AC power cable – DVI to DFP adapter – Video Signal Cable (15-pin mini D-SUB to DVI) – Video Signal Cable (DVI-D to DVI-D) – User’s manual. – NEC LCD Setup Software, Pivot Software and other helpful files.
E-5 Recommended Use English Recommended Use Safety Precautions and Maintenance Deutsch For optimum performance, please note the following when setting up and using the MultiSync LCD colour monitor: Français Español Italiano Appendix • DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to qualified service personnel.
Recommended Use E-6 • The inside of the fluorescent tube located within the LCD monitor contains mercury. Please follow the bylaws or rules of your local municipality to dispose of this tube properly. Immediately unplug your monitor from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the power supply cord or plug is damaged. • If liquid has been spilled or objects have fallen into the monitor.
E-7 Recommended Use English CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE FOLLOWING WHEN YOU POSITION THE MONITOR: Deutsch Français Español Italiano Appendix • For optimum performance, allow 20 minutes for warm-up. • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.
Installation E-8 English Installation Connection to your Personal Computer – the video controller is built into the computer. – the video controller is in the form of a display card (sometimes referred to as graphics card, video adapter or graphics board). To attach the MultiSync LCD1810X monitor to your system, follow these instructions: Français Both configurations have a video connector (or a CRT PORT on laptop computers).
E-9 Installation English NOTE: Some Macintosh systems do not require a Macintosh cable adapter. Deutsch 3. Remove connector cover. Connect the DVI signal cable to the connector on the back of the monitor. Connect the 15-pin mini D-SUB signal cable (not included) to the connector on the back of the monitor. Place the video signal cable (Figure C.1). Replace connector cover.
Installation E - 10 English Deutsch Figure A.2 Figure A.3 Français Figure A.1 Español Macintosh Cable Adapter (not included) Italiano CN912B-2/LCD1810X/78135322 25 Macintosh G3 and G4 do not need a Macintosh cable adapter 00.5.26, 0:03 PM Appendix Figure B.
E - 11 Installation English FigureC.1 Mini D-SUB Deutsch DVI Français Connector Cover Español FigureD.1 Power Cord Italiano Power Button Appendix Figure F.1 Figure E.1 CN912B-2/LCD1810X/78135322 26 00.5.
Installation E - 12 The monitor may be raised or lowered in either Portrait or Landscape mode. Screen Rotation Before rotating, the screen must be raised to the highest level to avoid knocking the screen on the desk or pinching your fingers. To rotate screen, place hands on each side of the monitor screen and turn clockwise from Landscape to Portrait or counter-clockwise from Portrait to Landscape (Figure R.1).
E - 13 Installation English Deutsch Figure RL.1 Français Español Figure R.1 Italiano Appendix Figure TS.1 CN912B-2/LCD1810X/78135322 28 00.5.
Installation E - 14 English Return the stand to its original position, remove the 4 screws that connect the monitor to the stand, and lift off the stand assembly. (Figure S.4) 5. Reverse this process to reattach stand. 55mm Français Figure S.1 3 1 Figure S.3 2 Español 4 Figure S.2 Deutsch NOTE: Use only VESA-compatible alternative mounting method. Figure S.
E - 15 Controls English Controls DVI/D-SUB : Allows you to change between the DVI-analog, DVIdigital and D-SUB signal inputs. Deutsch OSM Controls MUTE OSM Français EXIT CONTROL PROCEED RESET DVI/D-SUB The OSM controls on the front of the monitor provide the following functions: Español To access OSM menu, press any of the control buttons ( , , , ) or the PROCEED button. To mute sound function, press the EXIT button. To rotate OSM between Landscape and Portrait modes, press the RESET button.
Controls E - 16 Auto Adjust (Analog input only) Position Controls (Analog input only) CN912B-2/LCD1810X/78135322 31 00.5.26, 0:04 PM Appendix H. SIZE Adjusts the horizontal size by increasing or decreasing this setting. FINE Improves focus, clarity and image stability by increasing or decreasing this setting. AUTO ADJUST Automatically adjust H.SIZE and FINE settings.
E - 17 Controls English Colour Control System Deutsch Five colour presets select the desired colour setting. Each colour setting is adjusted at the factory. R,G,B: Increases or decreases Red, Green or Blue colour depending upon which is selected. The change in colour will appear on screen and the direction (increase or decrease) will be shown by the bars. Tools 1 Français Español Italiano Appendix SMOOTHING Select one of three image sharpness settings.
Controls E - 18 Español Italiano Appendix 00.5.26, 0:04 PM Français 33 Deutsch CN912B-2/LCD1810X/78135322 English VIDEO DETECT Selects the method of video detection when two computers are connected. NONE The monitor will not switch the video inputs automatically, only by user control. FIRST DETECT The video input has to be switched to “FIRST DETECT” mode. When current video input signal is not present, then the monitor searches for a video signal from the other video input port.
E - 19 Controls English Tools 2 Deutsch Français Español Italiano Appendix LANGUAGE OSM control menus are available in seven languages. OSM POSITION You can choose where you would like the OSM control image to appear on your screen. Selecting OSM Location allows you to manually adjust the position of the OSM control menu left, right, up or down. OSM TURN OFF The OSM control menu will stay on as long as it is in use.
Controls E - 20 OSM Warning Español Italiano NOTE: If “ CHANGE DVI SELECTION” is displayed, switch to DVI SELECTION. Français No Signal: This function gives a warning when there is no signal present. After power is turned on or when there is a change of input signal or video is inactive, the No Signal window will appear. The PROCEED button opens the DVI SELECTION CONTROL, as indicated in the section for DVI selection. Resolution Notifier: This function gives a warning of use with optimized resolution.
E - 21 Specifications English Specifications MultiSync LCD1810X Deutsch 46 cm (18.1 inch) viewable image size; 1280 x 1024 native resolution (Pixel Count); active matrix; thin film transistor (TFT); liquid crystal display (LCD); 0.28 mm dot pitch; 200 cd/m2 white luminance, typical; 300:1 contrast ratio, typical Input Signal (Analog) Video Analog 0.7 Vp-p 75 Ω Sync Separate sync. TTL Level Horizontal sync. Positive/Negative Vertical sync. Positive/Negative Composite sync.
Specifications Landscape Portrait Current Rating Dimensions AC 100-120 V / 220-240 V 50/60 Hz Landscape Portrait Hight Adjust 8.4 kg Temperature 5° C to + 35° C Humidity 30% to 80% Temperature -10° C to + 60° C Humidity 10% to 85% *1 Interpolated Resolutions: when resolutions are shown that are lower than the pixel Italiano count of the LCD module, text may appear choppy or lines may appear to be bold.
E - 23 Troubleshooting/Support English Troubleshooting/Support Check These Items No picture - The signal cable should be completely connected to the display card/computer. - The display card should be completely seated in its slot. - Power button and computer power switch should be in the ON position. - Check to make sure that a supported mode has been selected on the display card or system being used. (Please consult display card or system manual to change graphics mode.
Troubleshooting/Support E - 24 Image is unstable, unfocused or swimming is apparent - Signal cable should be completely attached to the computer. - Use the OSM Image Adjust controls to focus and adjust display by increasing or decreasing the Fine Control. When the display mode is changed, the OSM Image Adjust settings may need to be re-adjusted. - Check the monitor and your display card with respect to compatibility and recommended signal timings.
