Reference Guide

N8406-022A 1Gb Intelligent L2 Switch Smart Panel Reference Guide 65
Table 58 System Configuration Menu options
Command
Usage
rstctrl
Enables or disables reset when the panic occurs on the switch
software. The default value is enabled.
cur
Displays the current system parameters.
System host log configuration
Command: /cfg/sys/syslog
[Syslog Menu]
host - Set IP address of first syslog host
host2 - Set IP address of second syslog host
sever - Set the severity of first syslog host
sever2 - Set the severity of second syslog host
facil - Set facility of first syslog host
facil2 - Set facility of second syslog host
console - Enable/disable console output of syslog messages
log - Enable/disable syslogging of features
cur - Display current syslog settings
The following table describes the Syslog Configuration Menu options.
Table 59 Syslog Configuration Menu options
Command
Description
host <IP address>
Sets the IP address of the first syslog host. For example,
100.10.1.1
host2 <IP address>
Sets the IP address of the second syslog host. For
example,
100.10.1.2
sever <1-7>
Sets the severity level of the first syslog host displayed.
The default is 7, which means log all the severity levels.
sever2 <1-7>
Sets the severity level of the second syslog host displayed.
The default is 7, which means log all the severity levels.
facil <1-7>
This option sets the facility level of the first syslog host
displayed. The range is 0-7. The default is 0.
facil2 <1-7>
This option sets the facility level of the second syslog host
displayed. The range is 0-7. The default is 0.
console disable|enable
Enables or disables delivering syslog messages to the
console. When necessary, disabling console ensures the
switch is not affected by syslog messages. It is enabled by
default.
log <feature|all> <enable|disable>
Displays a list of features for which syslog messages can
be generated. You can choose to enable/disable specific
features or enable/disable syslog on all available features.
Features include:
console
system
mgmt
cli
vlan
ssh
ntp
ip
web
cfg
cur
Displays the current syslog settings.
