96
6. Using On-Screen Menu
Deleting the programs
1. On the [PROGRAM LIST] screen, select a program number you want to delete and press the SELECT
button.
2. Press the SELECT
button to select [DELETE].
3. Press the ENTER button.
The confirmation screen will be displayed.
4. Select [YES] and press the ENTER button.
The program will be deleted.
This will complete deleting the program.
Using [CORNERSTONE]
(
→
page 40)
Using [ENTRY LIST]
(
→
page 78)
Setting the Current Date and Time [DATE, TIME PRESET]
You can set the current time, month, date, and year.
NOTE: The projector has a built-in clock. The clock will keep working for about 2 weeks after the main power is turned off. If the
main power is off for 2 weeks or more, the built-in clock will cease. If the built-in clock ceases, set the date and time again. The
built-in clock will not cease while in the standby mode.
TIME ZONE: Select your time zone.
DAYLIGHT SAVING TIME: Place a check mark to adjust the clock for daylight saving changes.
INTERNET TIME SERVER: Place a check mark to turn on clock synchronization. When this option is turned on, the
projector’s built-in clock will be synchronized with an Internet timer server in every 24 hours and at the time of pro-
jector’s start up.
UPDATE button: Synchronizes the projector’s built-in clock immediately.
The UPDATE button is not available unless the INTERNET TIME SERVER check box is turned on.
Setting Mouse Pointer, Button and Sensitivity [MOUSE]
This option lets you to change your USB mouse settings. The mouse settings feature is available for USB mouse
only. Choose the settings you want:
MOUSE BUTTON
... [RIGHT HAND] or [LEFT HAND]
MOUSE SENSITIVITY
.. [FAST], [MEDIUM] or [SLOW]
Using [HELP]
(
→
page 36)
