AirCard 77xS / 34xU AT Command Reference 4114487 Rev 1
Preface Important Notice Due to the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost.
AirCard 77Xs / 34xU AT Command Reference Patents This product may contain technology developed by or for NETGEAR Inc. This product includes technology licensed from QUALCOMM®. This product is manufactured or sold by NETGEAR Inc. or its affiliates under one or more patents licensed from InterDigital Group and MMP Portfolio Licensing. Copyright © 2013 NETGEAR. All rights reserved.
Contents About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Command access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Command timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Interval timing . . . . . . . . . . . . . . . . . . . .
AirCard 77Xs / 34xU AT Command Reference SIM Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Command summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Command reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 OMA-DM Commands . . . . . . . . . .
1 1: About This Guide Introduction This document describes supported standard and proprietary AT commands available for NETGEAR AirCard™ devices, and provides details where commands vary from the standards. These commands are intended for use by OEMs, and are supplemental to the standard AT commands for GSM devices defined by the 3GPP (3rd Generation Partnership Project) in TS 27.007 AT command set for User Equipment (UE) and TS 27.
AirCard 77Xs / 34xU AT Command Reference Result codes Result codes are not shown in the command tables unless special conditions apply. Generally the result code OK is returned when the command has been executed. ERROR may be returned if parameters are out of range, and is returned if the command is not recognized or is not permitted in the current state or condition of the modem.
About This Guide Modem Status, Customization, and Reset Commands—Commands used to determine modem status, adjust customization settings, and reset the modem.
AirCard 77Xs / 34xU AT Command Reference Table 1-3: Mobile IP configuration commands (Continued) Command Description Page $QCMIPMHSS Set/return active profile’s Home Agent ‘shared secret’ (ASCII) 28 $QCMIPMHSSX Set/return active profile’s Home Agent ‘shared secret’ (Hexadecimal) 28 $QCMIPNAI Set/return active profile’s NAI 29 $QCMIPP Set/return the active profile 29 $QCMIPPHA Set/return active profile’s primary Home Agent address 30 $QCMIPSHA Set/return active profile’s secondary Home Ag
About This Guide Characters that are required are shown in uppercase; parameters are noted in lowercase. Required parameters are enclosed in angle brackets () while optional parameters are enclosed within square brackets ([x]). The brackets are not to be included in the command string. Commands are presented in table format. Each chapter covers the commands related to that subject and presents a summary table to help you locate a needed command.
AirCard 77Xs / 34xU AT Command Reference 12 Proprietary and Confidential 4114487
2 2: AT Password Commands Introduction AT commands described in this document are password-protected. This chapter describes how to enter and change the password. Command summary Table 2-1 on page 13 lists the commands described in this chapter. Table 2-1: AT password commands Command Description Page !ENTERCND Enable access to password-protected commands 14 !SETCND Set AT command password 14 Rev. 1 Sep.
AirCard 77Xs / 34xU AT Command Reference Command reference Table 2-2: AT command password details Command Description !ENTERCND Enable access to password-protected commands Before you can use any password-protected AT commands, you must enter the password correctly using this command. The initial password (“A710”) is configured onto the modem during manufacture. You can change the password using !SETCND.
3 3: Modem Status, Customization, and Reset Commands Introduction This chapter describes commands used to reset the modem, adjust customization settings, retrieve the hardware version, and monitor the temperature, voltage, and modem status. Command summary Table 3-1 lists the commands described in this chapter.
AirCard 77Xs / 34xU AT Command Reference Command reference Table 3-2: Modem status, customization, and reset commands Command Description !BAND Select/return frequency band set Note: The ‘Basic’ command and response versions are used if you haven’t entered the required password. (See Command access on page 7.) Configure the modem to operate on a set of frequency bands, look up available sets, create new sets, or return the current selection.
Modem Status, Customization, and Reset Commands Table 3-2: Modem status, customization, and reset commands (Continued) Command Description !BAND (continued) Select/return frequency band set (continued) Parameters: (Index of a band set. Use the Query List command to display all supported sets) • Valid range: 0–13 (Hexadecimal. There are 20 possible values.
AirCard 77Xs / 34xU AT Command Reference Table 3-2: Modem status, customization, and reset commands (Continued) Command Description $ERI Return current Enhanced Roaming Indicator (ERI) (For Sprint devices only) Return the current ERI. Password required: No. Usage: • Query: AT$ERI? Response: Returns Purpose: Display the modem’s current mode. Parameters: (Enhanced Roaming Indicator) • Decimal value as defined in Section 5.3.3 of Sprint Core Features User Interaction Requirements (version 1.0).
Modem Status, Customization, and Reset Commands Table 3-2: Modem status, customization, and reset commands (Continued) Command Description !GSTATUS Return operational status Return specific details about the current operational status of the modem. The response details vary depending on the current RAT. Contact NETGEAR for further details if required.
AirCard 77Xs / 34xU AT Command Reference Table 3-2: Modem status, customization, and reset commands (Continued) Command Description $MSID Set/report Mobile Station ID (MSID) (For Sprint devices only) Set or return the modem’s Mobile Station ID. Password required: No. Usage: • Execution: AT$MSID=, Purpose: Set the specified modem’s mobile station ID to . Note: This command returns “ERROR” if the is incorrect or if the is invalid.
Modem Status, Customization, and Reset Commands Table 3-2: Modem status, customization, and reset commands (Continued) Command Description !PCTEMP Return current temperature information Return the module’s temperature state and actual temperature. Password required: No Usage: • Query: AT!PCTEMP? Response: Temp state: Temperature: degC OK Purpose: Return the module’s temperature information.
AirCard 77Xs / 34xU AT Command Reference Table 3-2: Modem status, customization, and reset commands (Continued) Command Description $RESET or !RESET Reset (power cycle) modem $ROAM Set/report network roaming mode Immediately power cycle the device. (Note: $RESET is for Sprint devices only.) Password required: No. Usage: • Execution: AT!RESET Response: OK Purpose: Power cycles the device. • Execution: AT$RESET Purpose: Power cycles the device.
4 4: Mobile IP Commands Introduction This chapter describes commands used to configure and display Mobile IP options. Command summary Table 4-1 lists the commands described in this chapter.
AirCard 77Xs / 34xU AT Command Reference Command reference Table 4-2: Mobile IP commands Command Description $MIPERR Return last MIP error code (Sprint devices only) Return the last MIP error code that was received by the device. Password required: No Usage: • Execution: AT$MIPERR? Purpose: Return the last MIP error code. $QCMIP Set/return Mobile IP state Enable or disable Mobile IP (MIP) network authentication, or report the current state of MIP.
Mobile IP Commands Table 4-2: Mobile IP commands (Continued) Command Description $QCMIPGETP Identify active profile, or display specific profile’s configuration information Return the ID of the active profile, or display configuration information for a specific profile. Displayed information includes profile state (enabled, disabled), Home Address, Primary and Secondary Home Agent, etc. Password required: No Usage: • Execution: AT$QCMIPGETP= Response: List of configuration parameters.
AirCard 77Xs / 34xU AT Command Reference Table 4-2: Mobile IP commands (Continued) Command Description $QCMIPMASPI Set/return active profile’s AAA SPI Set or return the active profile’s Mobile Node AAA Security Parameter Index (SPI) Password required: No Usage: • Execution: AT$QCMIPMASPI=, Purpose: Set the active profile’s AAA SPI and indicate if it is to be committed to NV.
Mobile IP Commands Table 4-2: Mobile IP commands (Continued) Command Description $QCMIPMASSX Set/return active profile’s AAA ‘shared secret’ (Hexadecimal) Set or return the active profile’s Mobile Node AAA shared secret in hexadecimal format. Password required: No Usage: • Execution: AT$QCMIPMASSX=””, Purpose: Set the shared secret and indicate if it is to be committed to NV. Note: The command returns ERROR if is too long or if invalid characters are used.
AirCard 77Xs / 34xU AT Command Reference Table 4-2: Mobile IP commands (Continued) Command Description $QCMIPMHSS Set/return active profile’s Home Agent ‘shared secret’ (ASCII) Set or return the active profile’s Mobile Node Home Agent shared secret in ASCII format. Password required: No Usage: • Execution: AT$QCMIPMHSS=””, Purpose: Set the shared secret and indicate if it is to be committed to NV. Note: The command returns ERROR if is too long.
Mobile IP Commands Table 4-2: Mobile IP commands (Continued) Command Description $QCMIPNAI Set/return active profile’s NAI Set or return the active profile’s Network Address Identifier (NAI). Password required: No Usage: • Execution: AT$QCMIPNAI=””, Purpose: Set the NAI and indicate if it is to be committed to NV. • Query: AT$QCMIPNAI? Response: Returns and Purpose: Display the NAI and indicate if it is committed to NV.
AirCard 77Xs / 34xU AT Command Reference Table 4-2: Mobile IP commands (Continued) Command Description $QCMIPPHA Set/return active profile’s primary Home Agent address Set or return the active profile’s primary Home Agent (HA) IP address. Password required: No Usage: • Execution: AT$QCMIPPHA=””, Purpose: Set the primary HA address and indicate if it is to be committed to NV.
Mobile IP Commands Table 4-2: Mobile IP commands (Continued) Command Description $QCMIPRT Enable/disable reverse tunneling Enable or disable reverse tunneling. Password required: No Usage: • Execution: AT$QCMIPRT=, Purpose: Set the reverse tunneling state and indicate if it is to be committed to NV. • Query: AT$QCMIPRT? Response: Returns and Purpose: Display the reverse tunneling state and indicate if it is committed to NV.
AirCard 77Xs / 34xU AT Command Reference 32 Proprietary and Confidential 4114487
5 5: SIM Commands • Introduction • Command summary • Command reference Introduction This chapter describes commands used to communicate with an installed (U)SIM. Command summary Table 5-1 lists the commands described in this chapter: Table 5-1: SIM command passwords Command !ICCID Rev 1 Sep.
AirCard 77Xs / 34xU AT Command Reference Command reference Table 5-2: SIM command details Command Description !ICCID Return (U)SIM card’s ICCID Return a (U)SIM’s ICCID (Integrated Circuit Card ID). Password required: Yes Usage: • Query: AT!ICCID? Response: !ICCID: OK Purpose: Display the ICCID. Parameters: (ICCID of the (U)SIM currently being tested): • 20 digit decimal number—This number is often printed on the (U)SIM card.
6 6: OMA-DM Commands Introduction This chapter describes commands used to configure DM (Device Management) accounts, sessions, and host–device–server interactions. Command summary The table below lists the commands described in this chapter. Table 6-1: OMA-DM commands Command !IDSTEST Rev. 1 Sep.
AirCard 77Xs / 34xU AT Command Reference Command reference Table 6-2: OMA-DM command details Command Description !IDSTEST Start DM session (Sprint OMA activation) Start a specific type of DM session with a server. Password required: No Usage: • Execution: AT!IDSTEST=, Response: OK or ERROR Purpose: Start a session of a specified type for a specific account. • Query List: AT!IDSTEST=? Purpose: Display the execution command format and allowed parameter values.
7 7: Supported GSM/WCDMA AT Commands This chapter identifies standard AT commands that are supported by most NETGEAR AirCard devices. These commands: • Control serial communications over an asynchronous interface (ITU-T Serial Asynchronous Dialling and Control (Recommendation V.250), available on the International Telecommunication Union web site, www.itu.int). See Table 7-1 below. • Control SMS functions for devices on GSM/WCDMA networks (3GPP TS 27.005, available on the 3GPP web site, www.3gpp.
AirCard 77Xs / 34xU AT Command Reference Table 7-1: Supported ITU-T Recommendation V.
Table 7-1: Supported ITU-T Recommendation V.
AirCard 77Xs / 34xU AT Command Reference Table 7-2: Supported 27.
Table 7-3: Supported 27.
AirCard 77Xs / 34xU AT Command Reference Table 7-3: Supported 27.
Table 7-3: Supported 27.
AirCard 77Xs / 34xU AT Command Reference Table 7-3: Supported 27.
Table 7-3: Supported 27.007 AT commands (Continued) Command Description Supported =Yes; =No +CSVM Set Voice Mail Number +CTFR Call deflection +CTZR Time Zone Reporting +CTZU Automatic Time Zone Update +CUSD Unstructured supplementary service data +CV120 V.120 rate adaptation protocol +CVHU Voice Hangup Control +CVIB Vibrator mode D ITU T V.
AirCard 77Xs / 34xU AT Command Reference 46 Proprietary and Confidential 4114487
8 8: HSDPA/ HSUPA Categories The following tables describe standard HSDPA and HSUPA categories. Table 8-1: HSDPA-capable terminals Category Maximum number of supported HS-DSCH codes Minimum inter-TTI interval Number of soft values in terminal’s hybrid ARQ buffer Theoretical download maximum (L1 peak rate [Mbps]) Modulation Category 1 5 3 19,200 1.2 16QAM, QPSKa Category 2 5 3 28,800 1.2 16QAM, QPSKa Category 3 5 2 28,800 1.8 16QAM, QPSKa Category 4 5 2 38,400 1.
AirCard 77Xs / 34xU AT Command Reference 48 Proprietary and Confidential 4114487
9 9: Band Definitions Some commands described in this document include input and/or output ‘band’ parameters, where the band value is one of the following: • An enumerated value representing a network technology and band (Table 9-1) • A 3GPP band number (Table 9-2 on page 50) Note: Band support is product-specific—see the device’s Product Specification Document or Product Technical Specification for details.
AirCard 77Xs / 34xU AT Command Reference Table 9-2: 3GPP bands Frequency bands (MHz) Band 50 Rx Tx 1 1920–1980 2110–2170 2 1850–1910 3 Frequency bands (MHz) Rx Tx 20 832–862 791–821 1930–1990 21 1447.9–1462.9 1495.9–1510.9 1710–1785 1805–1880 22 Reserved Reserved 4 1710–1755 2110–2155 23 2000–2020 2180–2200 5 824–849 869–894 24 1626.5–1660.
10 10: ASCII Table Table 10-1: ASCII values Char Rev. 1 Sep.
AirCard 77Xs / 34xU AT Command Reference 52 Proprietary and Confidential 4114487
Index (AT commands) A A, answer incoming call, 38 A/, re-issue last AT command, 38 B !BAND, set/query frequency bands, 16 !BOOTHOLD, reset modem and wait for f/w download, 17 C &C, set data carrier detected, 37 C, ITU T v.
AirCard 77Xs / 34xU AT Command Reference +CMGR, read message, 39 +CMGS, send message, 39 +CMGW, write message to memory, 39 +CMMS, more messages to send, 39 +CMNA, new message acknowledgement to ME/TA, 39 +CMOD, call mode, 43 +CMS ERROR, SMS error (mobile or network error), 40 +CMSS, send message from storage, 40 +CMT, incoming message directly displayed, 40 +CMTI, incoming message stored at specific memory location, 40 +CMUX, multiplexing mode, 43 +CNMA, new message acknowledgement to ME, 40 +CNMI, new me
Index — AT Commands +ICF, set TE-TA control character framing, 38 !IDSTEST, start DM session, 36 +IFC, set TE-TA local data flow control, 38 +ILRR, set TE-TA local rate reporting mode, 38 +IPR, set fixed local rate, 38 $QCMIPT, Return RFC 2002bis authentication state, 31 $QRMCALL, make/disconnect data connection, 21 R L, set monitor speaker loudness, 38 !RESET, reset the modem, 22 $RESET, Reset (power cycle) the device, 22 $ROAM, Set/return roaming mode, 22 $RT, Reset device to factory defaults, 22 M
AirCard 77Xs / 34xU AT Command Reference 56 Proprietary and Confidential 4114487
Index Symbols E +++, 7 Enhanced Roaming Indicator. See ERI. ERI return current value, 18 escape sequence guard time, 7 Numerics 3GPP 27.005 commands, list, 39 27.007 commands, list, 40 F A ASCII table, 51 AT commands 3GPP 27.005 commands, list, 39 3GPP 27.007 commands, list, 40 access, password, 7 guard timing, escape sequence, 7 ITU-T V.
AirCard 77Xs / 34xU AT Command Reference last error code, return, 24 profile configuration, display, 25 reverse tunneling, enable/disable, 31 MM state and substate, return, 19 Mobile Directory Number. See MDN.
