112 | Chapter 6: Virtual Private Networking Using SSL
New Template Style Guide Reference Manual
Viewing SSL VPN Policies
To view the existing SSL VPN policies:
1. Select VPN > SSL VPN from the menu, and then select the Policies tab.
2. Make your selection from the following Query options:
• Click Global to view all global policies.
• Click Group to view group policies, and choose the relevant group’s name from the
drop-down list.
• Click User to view group policies, and choose the relevant user’s name from the
drop-down list.
3. Click the Display button. The List of SSL VPN Policies table displays the list for your
selected Query option.
Note: Global policies are displayed in the List of SSL VPN Policies table.
Policies that apply only to groups or users are displayed in the
Related Policies Table but not in the List of SSL VPN Policies
table.
