118 | Chapter 7: Managing Users, Authentication, and Certificates
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336Gv2 Reference Manual
To create a domain:
1. Select Users > Domains from the menu. The Domains screen is displayed.
2. Click Add. The Add Domain screen is displayed.
3. Configure the following fields:
a. Enter a descriptive name for the domain in the Domain Name field.
b. Select the Authentication Type.
The required fields are activated in varying combinations according to your selection of
Authentication Type:
Table 7-9. Authentication Type and Corresponding Required Fields
Authentication Type Required Authentication Information Fields
Local User Database None
Radius-PAP Authentication Server, Authentication Secret
Radius-CHAP Authentication Server, Authentication Secret
