Chapter 7: Managing Users, Authentication, and Certificates | 119
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336Gv2 Reference Manual
c. From the Select Portal drop-down list, select a portal with which this domain will be
associated.
4. Click Apply to save and apply your entries. The Domain screen displays a new domain
row.
5. If you use local authentication, make sure that it is not disabled: select the Yes radio
button in the Local Authentication section of the Domain screen (see ).
WARNING!
If you disable local authentication, make sure that there is at least
one external administrative user otherwise access to the network
storage is blocked.
6. If you change local authentication, click Apply in the Domain screen to save your
settings.
Creating a Group
The use of groups simplifies the configuration of VPN policies when different sets of users will
have different restrictions and access controls.
Note: Groups that are defined in the User screen are used for setting SSL
VPN policies. These groups should not be confused with LAN
Groups that are defined in the Network Configuration | LAN Settings
| LAN Groups tab, which are used to simplify firewall policies.
Radius-MSCHAP Authentication Server, Authentication Secret
Radius-MSCHAPv2 Authentication Server, Authentication Secret
WIKID-PAP Authentication Server, Authentication Secret
WIKID-CHAP Authentication Server, Authentication Secret
MIAS-PAP Authentication Server, Authentication Secret
MIAS-CHAP Authentication Server, Authentication Secret
NT Domain Authentication Server, Workgroup
Active Directory Authentication Server, Active Directory Domain
LDAP Authentication Server, LDAP Base DN
Table 7-9. Authentication Type and Corresponding Required Fields (Continued)
Authentication Type Required Authentication Information Fields
