Chapter 1: Introduction | 13
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336Gv2 Reference Manual
the following factory default information:
Figure 1-3 Product Lable
Qualified Web Browsers
To configure the network storage, you must use a Web browser such as Microsoft Internet
Explorer 6 or higher, Mozilla Firefox 3 or higher, or Apple Safari 3 or higher with JavaScript,
cookies, and you must have SSL enabled.
Although these Web browsers are qualified for use with the network storage’s Web
Management Interface for configuring the network storage, SSL VPN users should choose a
browser that supports JavaScript, Java, cookies, SSL, and ActiveX to take advantage of the
full suite of applications. Note that Java is only required for the SSL VPN portal, not the Web
Management Interface.
IP address
User name
Password
