140 | Chapter 8: VPN Firewall and Network Management
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336Gv2 Reference Manual
c. To allow access from a single IP address on the Internet, select Only this PC.
Enter the IP address that will be allowed access.
3. Configure the port number that will be used for secure HTTP management. The default
port number is 443.
4. To enable remote management by the command line interface (CLI) over Telnet, click
Yes to Allow Telnet Management, and configure the external IP addresses that will be
allowed to connect (see <pdf>“Using the Command Line Interface” on page 8-141).
a. To allow access from any IP address on the Internet, select Everyone.
b. To allow access from a range of IP addresses on the Internet, select IP address
range.
Enter a beginning and ending IP address to define the allowed range.
c. To allow access from a single IP address on the Internet, select Only this PC.
Enter the IP address that will be allowed access.
5. Click Apply to have your changes take effect.
Note: For enhanced security, restrict access to as few external IP
addresses as practical. See “Setting User Login Policies” on
page 121 for instructions on restricting administrator access. Be
sure to use strong passwords.
For accessing your VPN firewall from the Internet, the Secure Sockets Layer (SSL) will be
enabled. You will enter https:// (not http://) and type your VPN firewall’s WAN IP address into
your browser. For example, if your WAN IP address is 172.16.0.123, type the following in
your browser: https://172.16.0.123.
The VPN firewall’s remote login URL is https://<IP_address> or
https://<FullyQualifiedDomainName>.
• To maintain security, the VPN firewall will reject a login that uses http://address rather
than the SSL https://address.
• The first time you remotely connect to the VPN firewall with a browser via SSL, you may
get a warning message regarding the SSL certificate. If you are using a Windows
computer with Internet Explorer 5.5 or higher, simply click Yes to accept the certificate.
• If you are unable to remotely connect to the VPN firewall after enabling HTTPS remote
management, check whether other user policies, such as the default user policy, are
preventing access.
• If you disable HTTPS remote management, all SSL VPN user connections will also be
disabled.
