4. Select an NTP Server option:
• Use Default NTP Servers. The RTC is updated regularly by contacting a NETGEAR
NTP server on the Internet. A primary and secondary (backup) server are preloaded.
• Use Custom NTP Servers. To use a particular NTP server, enter the name or IP
address of the NTP Server in the Server 1 Name/IP Address field. You can enter the
address of a backup NTP server in the Server 2 Name/IP Address field. If you select
this option and leave either the Server 1 or Server 2 fields empty, they will be set to
the default Netgear NTP servers.
Note: If you select the default NTP servers or if you enter a custom server
FQDN, the VPN firewall must determine the IP address of the NTP
server by a DNS lookup. You must configure a DNS server address
on the WAN ISP Settings before the VPN firewall can perform this
lookup.
5. Click Apply to save your settings.
