Chapter 9: Monitoring System Performance | 148
Monitoring System Performance
9
This chapter describes the full set of system monitoring features of your ProSafe Dual WAN
Gigabit Firewall with SSL & IPsec VPN FVS336Gv2. You can be alerted to important events such
as WAN port rollover, WAN traffic limits reached, and login failures and attacks. You can also
view status information about the network storage, WAN ports, LAN ports, and VPN tunnels.
This chapter contains the following sections:
• Enabling the Traffic Meter” on this page.
• “Activating Notification of Events and Alerts” on page 150.
• “Viewing the Logs” on page 153.
• “Viewing VPN Firewall Configuration and System Status” on page 154.
• “Monitoring the Status of WAN Ports” on page 156.
• “Monitoring Attached Devices” on page 156.
• “Viewing the DHCP Log” on page 157.
• “Monitoring Active Users” on page 158.
• “Viewing Port Triggering Status” on page 159.
• “Monitoring VPN Tunnel Connection Status” on page 160.
• “Viewing the VPN Logs” on page 161.
