168 | Chapter 10: Troubleshooting
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336Gv2 Reference Manual
• Use the reset button on the rear panel of the VPN firewall. Use this method for cases
when the administration password or IP address is not known.
To restore the factory default configuration settings without knowing the administration
password or IP address, you must use the reset button on the rear panel of the VPN firewall.
To restore the factory defaults:
1. Press and hold the reset button until the Test LED begins to blink (about 10 seconds).
2. Release the reset button and wait for the VPN firewall to reboot.
Problems with Date and Time
The Time Zone screen displays the current date and time of day. The VPN firewall uses the
Network Time Protocol (NTP) to obtain the current time from one of several Network Time
Servers on the Internet. Each entry in the log is stamped with the date and time of day.
Problems with the date and time function can include:
• Date shown is January 1, 2000. Cause: The VPN firewall has not yet successfully
reached a Network Time Server. Check that your Internet access settings are configured
correctly. If you have just completed configuring the VPN firewall, wait at least five
minutes and check the date and time again.
• Time is off by one hour. Cause: The VPN firewall does not automatically sense Daylight
Savings Time. Go to the Time Zone screen (see “Configuring Date and Time Service” on
page 146), and select or cleare the Automatically Adjust for Daylight Savings Time
checkbox.
Using the Diagnostics Utilities
Note: For normal operation, diagnostics are not required.
You can perform diagnostics such as pinging an IP address, performing a DNS lookup,
displaying the routing table, rebooting the network storage, and capturing packets.
