Appendix A: Default Settings and Technical Specifications | 170
Default Settings and Technical
Specifications
A
You can use the reset button located on the rear panel to reset all settings to their factory
defaults. This is called a hard reset.
• To perform a hard reset, press and hold the reset button for approximately 10 seconds
(until the Test LED blinks rapidly). Your device will return to the factory configuration
settings shown in Table A-1.
• Pressing the reset button for a shorter period of time will simply reboots your device.
Table A-1. VPN firewall Default Configuration Settings
Feature Default Behavior
Router Login User Login URL https://192.168.1.1
User Name (case sensitive) admin
Login Password (case sensitive) password
Internet
Connection
WAN MAC Address Use Default address
WAN MTU Size 1500
Port Speed AutoSense
Local Network
(LAN)
LAN IP Address 192.168.1.1
Subnet Mask 255.255.255.0
RIP Direction None
RIP Version Disabled
RIP Authentication Disabled
DHCP Server Enabled
DHCP Starting IP Address 192.168.1.2
DHCP Ending IP Address 192.168.1.100
