Appendix A: Default Settings and Technical Specifications | 171
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336Gv2 Reference Manual
Technical specifications for the ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN are
listed in the following table.
Management Time Zone GMT
Time Zone Adjusted for Daylight
Saving Time
Disabled
SNMP Disabled
Remote Management Disabled
Firewall Inbound (communications coming in
from the Internet)
Denied
Outbound (communications from the
LAN to the Internet)
Allowed (all)
Source MAC filtering Disabled
Stealth Mode Enabled
Table A-2. VPN firewall Technical Specifications
Feature Specifications
Network Protocol
and Standards
Compatibility
Data and Routing Protocols: TCP/IP, RIP-1, RIP-2, DHCP
PPP over Ethernet (PPPoE)
Power Adapter North America: 120V, 60 Hz, input
United Kingdom, Australia: 240V, 50 Hz, input
Europe: 230V, 50 Hz, input
Japan: 100V, 50/60 Hz, input
Physical
specifications
Dimensions: 1.7 x 13 x 8.2 in.
Weight: 2 kg (4.5 lb)
Environmental
Specifications
Operating temperature: 0 to 40 C (32º to 104º F)
Operating humidity: 90% maximum relative humidity, noncondensing
Electromagnetic
Emissions
Meets requirements of: FCC Part 15 Class B
VCCI Class B
EN 55 022 (CISPR 22), Class B
Interface
Specifications
LAN: 10BASE-T or 100BASE-Tx 1000BASE-T, RJ-45
WAN: 10BASE-T or 100BASE-Tx 1000BASE-T, RJ-45
Table A-1. VPN firewall Default Configuration Settings (Continued)
Feature Default Behavior
