36 | Chapter 3: LAN Configuration
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336Gv2 Reference Manual
The Known PCs and Devices table lists the entries in the LAN Groups Database. For each
computer or device, the following fields are displayed:
• Name. The name of the PC or device. For computers that do not support the NetBIOS
protocol, this will be listed as “Unknown” (you can edit the entry manually to add a
meaningful name). If the computer was assigned an IP address by the DHCP server, then
the Name will be appended by an asterisk.
• IP Address. The current IP address of the computer. For DHCP clients of the VPN
firewall, this IP address will not change. If a computer is assigned a static IP addresses,
you will need to update this entry manually if the IP address on the computer has been
changed.
• MAC Address. The MAC address of the PC’s network interface.
• Group. Each PC or device can be assigned to a single group. By default, a computer is
assigned to Group 1, unless a different group is chosen from the Group drop-down list.
• Action. Allows modification of the selected entry by clicking Edit.
Adding Devices to the LAN Groups Database
To add devices manually to the LAN Groups Database, follow these steps:
1. In the Add Known PCs and Devices section, make the following entries:
• Name. Enter the name of the PC or device.
• IP Address Type. From the drop-down list, choose how this device receives its IP
address. The choices are:
- Fixed (Set on PC). The IP address is statically assigned on the computer.
- Reserved (DHCP Client). Directs the VPN firewall’s DHCP server to always assign
the specified IP address to this client during the DHCP negotiation (see “Configuring
DHCP Address Reservation” on page 37).
Note: When assigning a reserved IP address to a client, the IP address
selected must be outside the range of addresses allocated to the
DHCP server pool.
• IP Address. Enter the IP address that this computer or device is assigned in the IP
Address field. If the IP Address Type is Reserved (DHCP Client), the VPN firewall will
reserve the IP address for the associated MAC address.
• MAC Address. Enter the MAC address of the computer’s network interface in the
MAC Address field. The MAC address format is six colon-separated pairs of
hexadecimal characters (0-9 and A-F), such as 01:23:45:67:89:AB.
• Group. From the drop-down list, select the LAN Group to which the computer will be
assigned. (Group 1 is the default group.)
2. Click Add. The device will be added to the Known PCs and Devices table.
