Chapter 4: Firewall Protection and Content Filtering | 42
Firewall Protection and Content Filtering
4
This chapter describes how to use the content filtering features of the ProSafe Dual WAN Gigabit
Firewall with SSL & IPsec VPN FVS336Gv2 to protect your network.
This chapter contains the following sections:
• About Firewall Protection and Content Filtering” on this page.
• “Using Rules to Block or Allow Specific Kinds of Traffic” on page 43.
• “Configuring Other Firewall Features” on page 54.
• “Creating Services, QoS Profiles, and Bandwidth Profiles” on page 57.
• “Setting a Schedule to Block or Allow Specific Traffic” on page 61.
• “Blocking Internet Sites (Content Filtering)” on page 62.
• “Configuring Source MAC Filtering” on page 64.
• “Configuring IP/MAC Address Binding” on page 65.
• “Configuring Port Triggering” on page 66.
• “Managing the Application Level Gateway for SIP Sessions” on page 56.
• “E-Mail Notifications of Event Logs and Alerts” on page 68.
• “Administrator Tips” on page 69.
About Firewall Protection and Content Filtering
The VPN firewall provides you with Web content filtering options, plus browsing activity
reporting and instant alerts via e-mail. Network administrators can establish restricted access
policies based on time-of-day, Web addresses and Web address keywords. You can also
block Internet access by applications and services, such as chat or games.
A firewall is a special category of router that protects one network (the “trusted” network, such
as your LAN) from another (the untrusted network, such as the Internet), while allowing
communication between the two. You can further segment keyword blocking to certain known
groups (see “Managing Groups and Hosts (LAN Groups)” on page 34 to set up LAN Groups).
