Chapter 4: Firewall Protection and Content Filtering | 57
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336Gv2 Reference Manual
Creating Services, QoS Profiles, and Bandwidth
Profiles
When you create inbound and outbound firewall rules, you use firewall objects such as
services, QoS profiles, bandwidth profiles, and schedules to narrow down the firewall rules:
• Services. A service narrows down the firewall rule to an application and a port number.
For information about adding services, see “Adding Customized Services” on page 57.
• QoS profiles. A quality of service (QoS) profile defines the relative priority of an IP
packet for traffic that matches the firewall rule. For information about creating QoS
profiles, see “Setting Quality of Service (QoS) Priorities” on page 58.
• Bandwidth Profiles. A bandwidth profile allocates and limits traffic bandwidth for the
LAN users to which a firewall rule is applied. For information about creating bandwidth
profiles, see “Creating Bandwidth Profiles” on page 59.
Note: A schedule narrows down the period during which a firewall rule is
applied. For information about specifying schedules, see “Setting a
Schedule to Block or Allow Specific Traffic” on page 61.
Adding Customized Services
Services are functions performed by server computers at the request of client computers. For
example, Web servers serve Web pages, time servers serve time and date information, and
game hosts serve data about other players’ moves. When a computer on the Internet sends
a request for service to a server computer, the requested service is identified by a service or
port number. This number appears as the destination port number in the transmitted IP
packets. For example, a packet that is sent with destination port number 80 is an HTTP (Web
server) request.
The service numbers for many common protocols are defined by the Internet Engineering
Task Force (IETF) and published in RFC1700, “Assigned Numbers.” Service numbers for
other applications are typically chosen from the range 1024 to 65535 by the authors of the
application.
Although the VPN firewall already holds a list of many service port numbers, you are not
limited to these choices. Use the Services screen to add additional services and applications
to the list for use in defining firewall rules. The Services screen shows a list of services that
you have defined, as shown in .
To define a new service, you must first determine which port number or range of numbers is
used by the application. This information can usually be determined by contacting the
publisher of the application or from user groups or newsgroups. When you have the port
number information, you can enter it on the Services screen. You can configure up to 125
custom services.
