Chapter 5: Virtual Private Networking Using IPsec | 83
ProSafe Dual WAN Gigabit Firewall with SSL & IPsec VPN FVS336Gv2 Reference Manual
Managing VPN Policies
After you use the VPN Wizard to set up a VPN tunnel, a VPN policy and an IKE policy are
stored in separate policy tables. The name you selected as the VPN tunnel connection name
during Wizard setup identifies both the VPN policy and IKE policy.
You can edit existing policies, or add new VPN and IKE policies directly in the policy tables.
Note: You cannot modify an IKE policy that is associated with an enabled
VPN policy. To modify the IKE policy, first disable the VPN policy.
After you have modified and saved the IKE policy, you can then
re-enable the VPN policy.
Configuring IKE Policies
The IKE (Internet Key Exchange) protocol performs negotiations between the two VPN
gateways, and provides automatic management of the keys used in IPsec. It is important to
remember that:
• “Auto” generated VPN policies must use the IKE negotiation protocol.
• “Manual” generated VPN policies cannot use the IKE negotiation protocol.
IKE policies are activated when the following occur:
1. The VPN Policy Selector determines that some traffic matches an existing VPN policy. If
the VPN policy is of type “Auto”, then the Auto Policy Parameters defined in the VPN
policy are accessed which specify which IKE policy to use.
2. If the VPN policy is a “Manual” policy, then the Manual Policy Parameters defined in the
VPN policy are accessed and the first matching IKE policy is used to start negotiations
with the remote VPN gateway.
• If negotiations fail, the next matching IKE policy is used.
• If none of the matching IKE policies are acceptable to the remote VPN gateway, then
a VPN tunnel cannot be established.
3. An IKE session is established, using the SA (Security Association) parameters specified
in a matching IKE policy:
• Keys and other parameters are exchanged.
• An IPsec SA (Security Association) is established, using the parameters in the VPN
policy.
The VPN tunnel is then available for data transfer.
