350 East Plumeria Drive

San Jose, CA 95134

USA

June 2017

202-11765-01

24-Port Gigabit Smart Managed Pro

Switch with PoE+ and 2 SFP Ports

Model GS724TPv2

User Manual

Summary of content (317 pages)

PAGE 1
24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 User Manual June 2017 202-11765-01 350 East Plumeria Drive San Jose, CA 95134 USA
PAGE 2
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Support Thank you for purchasing this NETGEAR product. You can visit www.netgear.com/support to register your product, get help, access the latest downloads and user manuals, and join our community. We recommend that you use only official NETGEAR support resources. Conformity For the current EU Declaration of Conformity, visit http://kb.netgear.com/app/answers/detail/a_id/11621.
PAGE 3
Contents Chapter 1 Get Started Switch Management Interface Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Change the Default IP Address of the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Discover a Switch in a Network With a DHCP Server . . . . . . . . . . . . . . . . . . . . . 10 Discover a Switch in a Network Without a DHCP Server . . . . . . . . . . . . . . . . . . 11 Configure the Network Settings on Your Computer . . . . . . . . . . . . . . . . . . .
PAGE 4
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure SNMPv1/v2 Trap Flags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . View the Supported MIBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Configure SNMP V3 Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Configure LLDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 5
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 IGMP Snooping Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133 Configure IGMP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134 Configure IGMP Snooping for Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135 View the IGMP Snooping Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 6
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure Access Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 Configure Access Rule Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201 Configure Port Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202 Configure Global 802.1X Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 7
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Download a File to the Switch Using TFTP . . . . . . . . . . . . . . . . . . . . . . . . . . . 280 Download a File to the Switch Using HTTP . . . . . . . . . . . . . . . . . . . . . . . . . . . 282 Manage Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284 Configure Dual Image Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 8
1. 1 Get Started This manual describes how you can configure and operate the NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports, Model GS724TPv2 by using the web-based management interface. The manual describes the software configuration procedures and explains the options that are available within those procedures. This chapter provides an overview of how you can start your switch and access the web-based management interface.
PAGE 9
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Switch Management Interface Overview The switch provides administrative management options that let you configure, monitor, and control the network.
PAGE 10
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Discover a Switch in a Network With a DHCP Server This section describes how to set up your switch in a network that includes a DHCP server. The DHCP client on the switch is enabled by default. When you connect the switch to your network, the DHCP server automatically assigns an IP address to the switch. Use the Smart Control Center to discover the IP address automatically assigned to the switch.
PAGE 11
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The Smart Control Center launches a browser that displays the login page of the selected device. Use your web browser to manage your switch. The default password is password. For more information about the page layout and options, see Use a Web Browser to Access the Switch and Log In on page 16.
PAGE 12
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 9. Type your password to continue with the configuration change. Tip: You must enter the current password each time that you use the Smart Control Center to update the switch settings. The default password is password. 10. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately.
PAGE 13
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 following procedures show how to change the static IP address on a computer running a Microsoft Windows 7.  To modify the network settings on your computer: 1. Open the Control Panel and click the Network and Sharing Center option. 2. Click the Local Area Connection link. The Local Area Connection Status pop-window opens. 3. Click the Properties button. 4. Select Internet Protocol Version 4 (TCP/IPv4). 5.
PAGE 14
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 WARNING: When you change the IP address of your administrative system, you lose your connection to the rest of the network. Be sure to write down your current network address settings before you change them. 7. Click the OK button. 8. Close all other pop-up windows.  To configure a static address on the switch: 1.
PAGE 15
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Access the Web Browser–Based Management Interface You must be able to ping the IP address of the switch from your administrative system for web access to be available. If you used the Smart Control Center to set up the IP address and subnet mask, either with or without a DHCP server, use that IP address in the address field of your web browser.
PAGE 16
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Supported Web Browsers The following browsers were tested and support the web browser–based management interface. Later browser versions might function fine but were not tested. The supported web browsers include the following: • Microsoft Internet Explorer (IE) versions 10–12 • Mozilla Firefox versions 18–52 • Chrome versions 28–58 • Opera Versions 26–44 • Safari on Windows OS 5.1.
PAGE 17
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Navigation tab Configuration menus Help page Logout button Help link Buttons Configuration pages Configuration status and options Navigation Tabs, Configuration Menus, and Page Menu The navigation tabs along the top of the web interface give you quick access to the various switch functions. The tabs are always available and remain constant, regardless of which feature you configure.
PAGE 18
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configuration and Status Options The area directly under the configuration menus and to the right of the links displays the configuration information or status for the page you select. On pages that contain configuration options, you might be able to enter information into fields, select options from menus, select check boxes, and select radio buttons.
PAGE 19
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Web Browser–Based Management Interface Device View The Device View displays the ports on the switch. This graphic tool provides an alternate way to navigate to configuration and monitoring options. The graphic tool also provides information about device ports, configuration and status, tables, and feature components.  To use Device View: 1. Connect your computer to the same network as the switch.
PAGE 20
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 You can select a menu option to access the page that contains the configuration or monitoring options. If you right-click the graphic, but do not right-click a specific port, the main menu displays. This menu contains the same options as the navigation tabs at the top of the page. Right-click the specific port that you want to view or configure to see a menu that displays statistics and configuration options.
PAGE 21
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Interface Naming Conventions The switch supports physical and logical interfaces. Interfaces are identified by their type and the interface number. The physical ports are Gigabit interfaces and are numbered on the front panel. You configure the logical interfaces by using the software. The following table describes the naming convention for all interfaces available on the switch. Table 3.
PAGE 22
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Use these links as follows: • To display all ports, click the 1 link. • To display all LAGs, click the LAG link. • To display all ports and LAGs, click the All link. The procedures in this section describe how to select the ports and LAGs to configure. The procedures assume that you are already logged in to the switch.
PAGE 23
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 4. Configure the desired settings. 5. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately.  To configure a single port: 1. Ensure that the page is displaying all ports, and not only the LAGs. 2. Select the check box next to the port number. The row for the selected interface is highlighted, and the interface number appears in the heading row. 3.
PAGE 24
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 3. Configure the desired settings. 4. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately.  To configure multiple LAGs: 1. Click the LAG link or the All link to display the LAGs. 2. Select the check box next to each LAG to configure. The check box associated with each interface is selected, and the row for each selected interface is highlighted. 3.
PAGE 25
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2  To configure all LAGs: 1. Click the LAG link to display only the LAG interfaces. 2. Select the check box in the heading row. The check box associated with every LAG is selected, and the rows for all LAGs are highlighted. 3. Configure the desired settings. 4. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately.
PAGE 26
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2  To access the support website from the web browser–based management interface: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 27
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. To access the NETGEAR download center, click the Apply button. 7. Enter the model number of the switch. 8. Locate the user manual on the product support web page. Register Your Product To qualify for product updates and product warranty, we encourage you to register your product. The first time you log in to the switch, you are given the option of registering with NETGEAR.
PAGE 28
2.
PAGE 29
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 View and Configure the Switch Management Settings This section describes how you can display the switch status and specify some basic switch information, such as the management interface IP address, system clock settings, and DNS information.
PAGE 30
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Define the following fields: • System Name. Enter the name to identify this switch. You can use up to 255 alphanumeric characters. The default is blank. • System Location. Enter the location of this switch. You can use up to 255 alphanumeric characters. The default is blank. • System Contact. Enter the contact person for this switch. You can use up to 255 alphanumeric characters. The default is blank. 6.
PAGE 31
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 8. To refresh the page, click the Update button. The following table describes the nonconfigurable information displayed in the Versions section of the System Information page. Field Description Model Name The model name of the switch. Boot Version The version of the bootloader software of the switch. Software Version The version number of the code currently running on the switch.
PAGE 32
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • Dynamic IP Address (BOOTP). Specifies that the switch must obtain the IP address through a BootP server. • Static IP Address. Specifies that the IP address, subnet mask, and default gateway must be manually configured. Enter this information in the fields below this radio button. 7. If you selected the Static IP Address radio button, configure the following network information: • IP Address.
PAGE 33
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure the IPv6 Network Interface You can configure the IPv6 network interface, which is the logical interface used for in-band connectivity with the switch through all of the switch’s front-panel ports. The configuration parameters associated with the switch’s network interface do not affect the configuration of the front panel ports through which traffic is switched or routed.
PAGE 34
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 b. In the EUI64 menu, select True to enable the Extended Universal Identifier (EUI) flag for IPv6 address, or select False to omit the EUI flag. c. Click the Add button. 10. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately.
PAGE 35
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 4. IPv6 network interface neighbor table information (continued) Field Description IsRtr • • Neighbor State The state of the neighboring switch: • reachable (1). The neighbor is reachable by this switch. • stale (2). Information about the neighbor is scheduled for deletion. • delay (3). No information was received from the neighbor during the delay period. • probe (4).
PAGE 36
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select the Clock Source Local radio button. 7. In the Date field, specify the current date in months, days, and years (MM/DD/YYYY). 8. In the Time field, specify the current time in hours, minutes, and seconds (HH:MM:SS). Note: If you select the Clock Source Local radio button and enter information in the Date and Time fields, over a period of time, the date and time might become inaccurate.
PAGE 37
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The page refreshes and displays the SNTP Global Configuration section and the SNTP Global Status section. The default is SNTP. The local clock can be set to SNTP only if the following two conditions are met: • The SNTP server is configured. • The SNTP last attempt status is successful. 7. Next to Client Mode, select the mode of operation of the SNTP client: • Disable. SNTP is not operational.
PAGE 38
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 You can also specify the number of hours and number of minutes that the time zone is different from the Coordinated Universal Time (UTC). The time zone can affect the display of the current system time. The default is UTC. Note: When using SNTP/NTP time servers to update the switch’s clock, the time data received from the server is based on the UTC, which is the same as Greenwich Mean Time (GMT).
PAGE 39
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select a Client mode radio button to specify the mode of operation of the SNTP client: • Disable. SNTP is not operational. No SNTP requests are sent from the client and no received SNTP messages are processed. • Unicast. SNTP operates in a point-to-point fashion.
PAGE 40
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The allowed range is 1 to 30. The default is 5. 11. In the Unicast Poll Retry field, specify the number of times to retry a unicast poll request to an SNTP server after the first time-out before the switch attempts to use the next configured server. The allowed range is 0 to 10. The default is 1. 12. In the Time Zone Name field, specify a time zone.
PAGE 41
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select System > Management > Time > Time Configuration > SNTP Global Status. When you select the SNTP option as the clock source, the SNTP Global Status is displayed below the SNTP Global Configuration section. 6.
PAGE 42
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 5. SNTP Global Status information (continued) Field Description Last Attempt Status The status of the last SNTP request or unsolicited message for both unicast and broadcast modes. If no message was received from a server, a status of Other is displayed. These values are appropriate for all operational modes. • Other. The status of the last request is unknown. • Success.
PAGE 43
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following is an example of strata: • Stratum 0. A real-time clock is used as the time source, for example, a GPS system. • Stratum 1. A server that is directly linked to a Stratum 0 time source is used. Stratum 1 time servers provide primary network time standards. • Stratum 2. The time source is distanced from the Stratum 1 server over a network path.
PAGE 44
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The System Information page displays. 5. Select System > Management > Time > SNTP Server Configuration. 6. From the Server Type menu, select the type of SNTP address to enter in the address field. The address can be either an IP address (IPv4, IPv6) or a host name (DNS). The default is IPv4. 7. In the Address field, specify the IP address or the host name of the SNTP server.
PAGE 45
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The SNTP Server Status table displays status information about the SNTP servers configured on your switch. The following table describes the fields in the SNTP Server Status table. Table 6. SNTP Server Status information Field Description Address All the existing server addresses. If no server configuration exists, a message stating that no SNTP server exists displays on the page.
PAGE 46
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The default password is password. The System Information page displays. 5. Select System > Management > Time > SNTP Server Configuration. The SNTP Server Configuration page displays. 6. Select the check box next to the configured server. 7. Specify new values in the available fields. 8. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately.
PAGE 47
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2  To configure the daylight saving time settings: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 48
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The updated configuration is sent to the switch. Configuration changes take effect immediately. The fields that are described in the following table are visible on the page only if the DayLight Saving (DST) Recurring, Recurring EU, or Recurring USA radio button is selected. Table 7.
PAGE 49
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 8. Daylight saving setting is Non Recurring (continued) Field Description Offset Specify the number of minutes to shift the summer time from the standard time. The valid range is 1–1440 minutes. Zone Specify the acronym associated with the time zone when summer time is in effect. This field is not validated against an official list of time zone acronyms.
PAGE 50
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table displays the nonconfigurable information on the page. Table 9. Daylight Saving (DST) Status information Field Description Daylight Saving (DST) The Daylight Saving value, which is one of the following: • Disable • Recurring • Recurring EU • Recurring USA • Non Recurring Begins At Displays when the daylight saving time begins. This field is not displayed when daylight saving time is disabled.
PAGE 51
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The default password is password. The System Information page displays. 5. Select System > Management > Denial of Service > Auto-DoS Configuration. The Auto-DoS Configuration page displays. 6. Next to Auto-DoS Mode, select the Enable radio button. When an attack is detected, a warning message is logged to the buffered log and is sent to the syslog server.
PAGE 52
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select the types of DoS attacks for the switch to monitor and block and configure any associated values: • Denial of Service ICMPv4. Enabling ICMPv4 DoS prevention causes the switch to drop ICMPv4 packets with a type set to ECHO_REQ (ping) and a size greater than the configured ICMPv4 packet size. • Denial of Service Max ICMPv4 Packet Size. Specify the maximum ICMPv4 packet size allowed.
PAGE 53
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select the Disable or Enable radio button to specify whether to disable or enable the administrative status of the DNS client. • Enable. Allow the switch to send DNS queries to a DNS server to resolve a DNS domain name. The DNS is enabled by default. • Disable. Prevent the switch from sending DNS queries. 7. In the DNS Default Name field, enter the default DNS domain name to include in DNS queries.
PAGE 54
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the fields that are shown in the DNS Server Configuration table. Table 10. DNS Server Configuration information Field Description ID The identification of the DNS Server. Preference Shows the preference of the DNS server. The preferences are determined by the order in which they were entered.
PAGE 55
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Remove an Entry From the Dynamic Host Mapping Table  To remove an entry from the dynamic host mapping table: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 56
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select the check box next to the entry to update. 7. Enter the new information in the appropriate field. 8. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. 9. To clear all the dynamic host name entries from the list, click the Clear button. The Dynamic Host Mapping table shows host name-to-IP address entries that the switch learned.
PAGE 57
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select the EEE Mode Disable or Enable radio button. Energy Efficient Ethernet (EEE) combines the MAC with a family of physical layers that support operation in a low-power mode. It is defined by IEEE 802.3az Energy Efficient Task Force. Lower power mode enables both the send and receive sides of the link to disable some functionality for power savings when lightly loaded.
PAGE 58
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select one or more interfaces by taking one of the following actions: • To configure a single interface, select the check box associated with the port, or type the port number (for example, g1) in the Go To Interface field and click the Go button. • To configure multiple interfaces with the same settings, select the check box associated with each interface.
PAGE 59
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 sure that the devices connected to the higher-priority, lower-numbered PoE ports are supported first. Although a device is listed as an 802.3at PoE+-powered or 802.3af PoE-powered device, it might not require the maximum power limit that is specified by its IEEE standard.
PAGE 60
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the nonconfigurable fields on the page. Table 12. PoE Configuration fields Field Description Firmware Version The firmware version of the PoE firmware component. Power Status The power status. Nominal Power The maximum amount of power in watts that the switch can deliver to all ports.
PAGE 61
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select one or more ports by taking one of the following actions: • To configure a single port, select the check box associated with the port, or type the port number (for example, g1) in the Go To Interface field and click the Go button. • To configure multiple ports with the same settings, select the check box associated with each interface.
PAGE 62
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 For information about setting up and configuring PoE timer schedules, see Set Up PoE Timer Schedules on page 87. 12. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. The following table describes the nonconfigurable fields on the page. Table 13. PoE Port Configuration Field Description High Power All ports supports high-power mode.
PAGE 63
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure SNMP You can configure SNMP settings for SNMPv1/v2 and SNMPv3. The switch supports the configuration of SNMP groups and users that can manage traps that the SNMP agent generates. The switch uses both standard public MIBs for standard functionality and private MIBs that support additional switch functionality. The main object for interface configuration is in NetgearSmartSwitch-MIB, which is a private MIB.
PAGE 64
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Together, the management station IP and the management station IP mask denote a range of IP addresses from which SNMP clients can use that community to access this device. If either the management station IP or management station IP mask value is 0.0.0.0, access is allowed from any IP address. Otherwise, every client’s address is ANDed with the mask, as is the management station IP address.
PAGE 65
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The updated configuration is sent to the switch. Configuration changes take effect immediately. Delete an SNMP Community  To delete an SNMP community: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 66
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select System > SNMP > SNMP V1/V2 > Trap Configuration. 6. In the Recipients IP field, enter the IPv4 address in the x.x.x.x format to receive SNMP traps from this device. 7. From the Version menu, select the trap version to be used by the SNMP trap receiver.
PAGE 67
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The System Information page displays. 5. Select System > SNMP > SNMP V1/V2 > Trap Configuration. The Trap Configuration page displays. 6. Select the check box next to the recipient. 7. Update the desired fields. 8. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. Delete an SNMP Recipient  To delete an SNMP trap recipient: 1.
PAGE 68
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure SNMPv1/v2 Trap Flags You can enable or disable traps that the switch can send to an SNMP manager. When the condition identified by an active trap is encountered by the switch, a trap message is sent to any enabled SNMP trap receivers, and a message is written to the trap log.  To configure the trap flags: 1. Connect your computer to the same network as the switch.
PAGE 69
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 View the Supported MIBs You can view a list of all MIBs that are supported by the switch.  To view the supported MIBs: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 70
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure SNMP V3 Users Any user can connect to the switch using the SNMPv3 protocol, but for authentication and encryption, the switch supports only one user (admin). Therefore, you can create or modify only one profile.  To configure authentication and encryption settings for the SNMPv3 admin profile by using the web interface: 1. Connect your computer to the same network as the switch.
PAGE 71
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure LLDP The IEEE 802.1AB-defined standard, Link Layer Discovery Protocol (LLDP), allows stations on an 802 LAN to advertise major capabilities and physical descriptions. This information is viewed by a network manager to identify system topology and detect bad configurations on the LAN.
PAGE 72
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select System > LLDP > Basic > LLDP Configuration. 6.
PAGE 73
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure LLDP Port Settings You can specify per-interface LLDP settings.  To configure the LLDP interface: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 74
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 - Tx and Rx. Enable both transmitting and receiving LLDP PDUs on the selected ports. - Disabled. Do not transmit or receive LLDP PDUs on the selected ports. The default is Tx and Rx. • Management IP Address. Choose whether to advertise the management IP address from the interface. The possible field values are as follows: - Stop Advertise. Do not advertise the management IP address from the interface.
PAGE 75
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The System Information page displays. 5. Select System > LLDP > Advanced > LLDP-MED Network Policy. The LLDP-MED Network Policy page displays. 6. From the Interface menu, select the interface for which you want to view the information. Note: The menu includes only the interfaces on which LLDP is enabled. If no interfaces are enabled for LLDP, the Interface menu does not display.
PAGE 76
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure LLDP-MED Port Settings You can enable LLDP-MED mode on an interface and configure its properties.  To configure LLDP-MED settings for a port: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 77
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 View Local LLDP Information You can view the data that each port advertises through LLDP.  To view local LLDP information: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 78
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Field Description System Capabilities The primary functions that the switch supports. Interface The interface associated with the rest of the data in the row. Port ID Subtype The type of information used to identify the interface in the Port ID field. Port ID The port number. Port Description The user-defined description of the port.
PAGE 79
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Field Description Network Policies Application Type The media application type associated with the policy. VLAN ID The VLAN ID associated with the policy. VLAN Type Specifies whether the VLAN associated with the policy is tagged or untagged. User Priority The priority associated with the policy. DSCP The DSCP associated with a particular policy type.
PAGE 80
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the information that displays for all LLDP neighbors that were discovered. Field Description MSAP Entry The Media Service Access Point (MSAP) entry number for the remote device. Local Port The interface on the local system that received LLDP information from a remote system. Chassis ID Subtype The type of data displayed in the Chassis ID field on the remote system.
PAGE 81
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Field Description Managed Addresses Address SubType The type of the management address. Address The advertised management address of the remote system. Interface SubType The port subtype. Interface Number The port on the remote device that sent the information. MAC/PHY Details Auto-Negotiation Supported Specifies whether the remote device supports port-speed autonegotiation.
PAGE 82
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Field Description Location Information Civic The physical location, such as the street address, that the remote device advertised in the location TLV, for example, 123 45th St. E. The field value length range is 6–160 characters. Coordinates The location map coordinates that the remote device advertised in the location TLV, including latitude, longitude, and altitude.
PAGE 83
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure the Global DHCP Snooping Settings You can view and configure the global settings for DHCP snooping.  To configure the global DHCP snooping settings: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 84
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Enable DHCP for All Interfaces in a VLAN  To enable DHCP snooping for all interfaces that are members of a VLAN: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 85
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The default password is password. The System Information page displays. 5. Select System > Services > DHCP Snooping > Interface Configuration. 6. Select one or more interfaces by taking one of the following actions: • To configure a single interface, select the check box associated with the port, or type the port number in the Go To Interface field and click the Go button.
PAGE 86
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Binding Configuration You can view, add, and remove static bindings in the DHCP snooping bindings database and view or clear the dynamic bindings in the bindings table.  To configure static DHCP bindings: 1. Connect your computer to the same network as the switch.
PAGE 87
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 16. DHCP Dynamic Configuration information Field Description Interface The interface on which the DHCP client message was received. MAC Address The MAC address associated with the DHCP client that sent the message. This is the key to the binding database. VLAN ID The VLAN ID of the client interface. IP Address The IP address assigned to the client by the DHCP server.
PAGE 88
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select System > Timer Schedule > Basic > Timer Global Configuration. 6. Select the Admin Mode Enable radio button. By default, the Disable button is selected and PoE timer schedules are disabled. 7. In the Timer Schedule Name field, specify the name for a timer schedule. 8. Click the Add button. The timer schedule is added to the Timer Schedule Name table and is assigned an ID.
PAGE 89
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. From the Timer Schedule Name menu, select the name of the timer schedule that you want to configure. You can select only names of schedules that you created (see Create a PoE Timer Schedule on page 87). 7. In the Shutdown Time Start field, enter the time of day in the HH:MM format to specify when the timer schedule must start. 8.
PAGE 90
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 In the Every Month(s) field, enter a number from 0 to 65534 to specify that the schedule must be triggered every specified number of months. If the number of months is not specified, or if you enter 0, then the schedule is triggered only once. - Lower Day radio button and field. Select an option from both the left menu and right menu.
PAGE 91
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select System > Timer Schedule > Advanced > Timer Global Configuration. The Timer Schedule Configuration page displays. 6. Select the check box for the timer schedule that you want to delete. You can simultaneously delete multiple or all timer schedules. 7. Click the Delete button. The timer schedule is deleted.
PAGE 92
3.
PAGE 93
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure Port Settings You can view, configure, and monitor the physical port information for the ports (that is, the physical interfaces) on the switch.  To configure port settings: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2.
PAGE 94
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Note: After you change the autonegotiation mode, the switch might be inaccessible for a number of seconds while the new settings take effect. 10. In the Speed field, specify the speed value for the selected port. Possible field values are as follows: • Auto. All supported speeds. This is the default setting. • 10Mbps. 10 Mbits/second. • 100Mbps. 100 Mbits/second. • 1000Mbps. 1000 Mbits/second.
PAGE 95
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 a pause frame to stop traffic on a port if the amount of memory used by the packets on the port exceeds a preconfigured threshold and responds to pause requests from partner devices. The paused port does not forward packets for the period of time specified in the pause frame.
PAGE 96
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure LAG Settings You can group one or more full-duplex Ethernet links to be aggregated together to form a link aggregation group, which is also known as a port channel. The switch treats the LAG as if it were a single link.  To configure LAG settings: 1. Connect your computer to the same network as the switch.
PAGE 97
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 9. From the STP Mode menu, select the Spanning Tree Protocol (STP) administrative mode associated with the LAG. The possible values are as follows: • Disable. Spanning tree is disabled for this LAG. • Enable. Spanning tree is enabled for this LAG. Enable is the default. 10. From the Link Trap menu, select Enable or Disable to specify whether to send a trap when the link status changes.
PAGE 98
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The default password is password. The System Information page displays. 5. Select Switching > LAG > Basic > LAG Membership. 6. From the LAG ID menu, select the LAG ID. 7. In the LAG Name field, enter the name to be assigned to the LAG. You can enter any string of up to 15 alphanumeric characters. A valid name must be specified for you to create the LAG. 8.
PAGE 99
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The System Information page displays. 5. Select Switching > LAG > Advanced > LACP Configuration. 6. In the LACP System Priority field, specify the device’s link aggregation priority relative to the devices at the other ends of the links on which link aggregation is enabled. A higher value indicates a lower priority. You can change the value of the parameter globally by specifying a priority from 1 to 65535.
PAGE 100
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select one or more interfaces by taking one of the following actions: • To configure a single interface, select the check box associated with the interface, or type the interface number in the Go To Interface field and click the Go button. • To configure multiple interfaces with the same settings, select the check box associated with each interface.
PAGE 101
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Each VLAN in a network is assigned an associated VLAN ID, which appears in the IEEE 802.1Q tag in the Layer 2 header of packets transmitted on a VLAN. An end station can omit the tag, or the VLAN portion of the tag, in which case the first switch port to receive the packet can either reject it or insert a tag using its default VLAN ID.
PAGE 102
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 7. In the VLAN Name field, specify a name for the VLAN. The VLAN name can be up to 32 alphanumeric characters long, including blanks. The default is blank. VLAN ID 1 always uses the name Default. 8. The VLAN Type field displays the type of the VLAN that you are configuring. You cannot change the type of the default VLAN (VLAN ID = 1): it is always type Default.
PAGE 103
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Reset a VLAN to Its Default Settings  To reset a VLAN to its default settings: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 104
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Switching > VLAN > Advanced > VLAN Membership. 6. In the VLAN ID menu, select the VLAN ID. 7.
PAGE 105
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • U (Untagged). Select the LAGs on which all frames transmitted for this VLAN are untagged. The LAGs that are selected are included in the VLAN. 10. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. The following table describes the nonconfigurable information on the page. Table 19.
PAGE 106
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the nonconfigurable information on the page. Table 20. VLAN status Field Definition VLAN ID The VLAN identifier (VID) of the VLAN. The range of the VLAN ID is 1 to 4093. VLAN Name The name of the VLAN. VLAN ID 1 is always named Default. VLAN Type The VLAN type: • Default (VLAN ID = 1). Always present. • Static. A VLAN that you configured.
PAGE 107
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Switching > VLAN > Advanced > Port PVID Configuration. 6. To display information for all physical ports and LAGs, click the ALL link. 7. Select interfaces by selecting the Interface check boxes next to the interfaces. You can select multiple interfaces.
PAGE 108
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 12. From the Ingress Filtering menu, select one of the following options: • Enable. The frame is discarded if this port is not a member of the VLAN with which this frame is associated. In a tagged frame, the VLAN is identified by the VLAN ID in the tag. In an untagged frame, the VLAN is the port VLAN ID specified for the port that received this frame. • Disable. All frames are forwarded in accordance with the 802.
PAGE 109
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select Switching > VLAN > Advanced > Voice VLAN Configuration. 6. Select the Admin Mode Disable or Enable radio button. This specifies the administrative mode for the voice VLAN for the switch. The default is Disable. 7.
PAGE 110
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 12. In the DSCP Value field, configure the Voice VLAN DSCP value for the port. The valid range is 0 to 63. The default is 0. The Operational State field displays the operational status of the voice VLAN on the given interface. 13. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately.
PAGE 111
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select Switching > Auto-VoIP > Protocol-based > Port Settings. 6. From the Prioritization Type menu, select Traffic Class or Remark. This specifies the type of prioritization. 7. From the Class Value menu, specify the CoS tag value to be reassigned for packets received on the voice VLAN when Remark CoS is enabled. 8. Click the Apply button. The updated configuration is sent to the switch.
PAGE 112
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select Switching > Auto-VoIP > OUI-based > Properties. 6. In the Auto-VoIP VLAN ID field, enter the VoIP VLAN ID of the switch. No default VLAN exists for Auto-VoIP, you must create a VLAN for Auto-VoIP. 7. From the OUI-based priority menu, select the OUI-based priority of the switch. The default is 7. 8. Click the Apply button. The updated configuration is sent to the switch.
PAGE 113
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select one or more interfaces by taking one of the following actions: • To configure a single interface, select the check box associated with the port, or type the port number in the Go To Interface field and click the Go button. • To configure multiple interfaces with the same settings, select the check box associated with each interface.
PAGE 114
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • 00:E0:75: VERILINK • 00:E0:BB: 3COM • 00:04:0D: AVAYA1 • 00:1B:4F: AVAYA2 • 00:04:13: SNOM You can select an existing OUI or add a new OUI and description to identify the IP phones on the network. Configure the OUI Table  To configure the OUI Table: 1. Connect your computer to the same network as the switch.
PAGE 115
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 7. In the Description field, enter the description for the OUI. The maximum length of description is 32 characters. The following OUIs are present in the configuration by default: • 00:01:E3 - SIEMENS • 00:03:6B - CISCO1 • 00:12:43 - CISCO2 • 00:0F:E2 - H3C • 00:60:B9 - NITSUKO • 00:D0:1E - PINTEL • 00:E0:75 - VERILINK • 00:E0:BB - 3COM • 00:04:0D - AVAYA1 • 00:1B:4F - AVAYA2 8.
PAGE 116
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Display the Auto-VoIP Status You can display the Auto-VoIP status.  To view the Auto-VoIP status: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 117
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure Spanning Tree Protocol The Spanning Tree Protocol (STP) provides a tree topology for any arrangement of bridges. STP also provides one path between end stations on a network, eliminating loops. Spanning tree versions supported include Common STP, Multiple STP, and Rapid STP. Classic STP provides a single path between end stations, avoiding and eliminating loops.
PAGE 118
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select Switching > STP > Basic > STP Configuration. The following figure does not show the STP Status section on the page. 6. Configure the following options: • Spanning Tree State. Enable or disable the spanning tree operation on the switch. • STP Operation Mode. Specify the STP version for the switch. The options are STP, RSTP, and MSTP. • Configuration Name.
PAGE 119
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 23. STP configuration status (continued) Field Description Root Port Port to access the designated root for the CST. Max Age (secs) The maximum age timer controls the maximum length of time in seconds that passes before a bridge port saves its configuration BPDU information. Forward Delay (secs) The derived value of the Root Port Bridge Forward Delay parameter.
PAGE 120
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Specify the CST options: • Bridge Priority. When switches or bridges are running STP, each is assigned a priority. After exchanging BPDUs, the switch with the lowest priority value becomes the root bridge. Specify the bridge priority value for the Common and Internal Spanning Tree (CST). The valid range is 0–61440. The bridge priority is a multiple of 4096.
PAGE 121
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure CST Port Settings You can configure Common Spanning Tree (CST) and Internal Spanning Tree on a specific port on the switch. A port can become diagnostically disabled (D-Disable) when DOT1S experiences a severe error condition. The most common cause is when the DOT1S software experiences BPDU flooding. The flooding criteria are such that DOT1S receives more than 15 BPDUs in a 3-second interval.
PAGE 122
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 7. From the STP Status menu, select the option to enable or disable the spanning tree administrative mode that is associated with the port or port channel. The possible values are Enable and Disable. The default is Enable. 8. From the Fast Link menu, select whether the specified port is an edge port within the CST. The possible values are Enable and Disable. The default is Enable. 9.
PAGE 123
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Switching > STP > Advanced > CST Port Status. 6. To refresh the page with the latest information about the switch, click the Update button.
PAGE 124
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 25. CST port status (continued) Field Description CST Regional Root Bridge identifier of the CST regional root. It is made up using the bridge priority and the base MAC address of the bridge. CST Path Cost Path cost to the CST regional root. Port Forwarding State The forwarding state of this port.
PAGE 125
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Manage MST Settings You can configure Multiple Spanning Tree (MST) on the switch. Configure an MST Instance  To configure an MST instance: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 126
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the nonconfigurable information on the page. Table 27. MST configuration Field Description Bridge Identifier The bridge identifier for the selected MST instance. It is made up using the bridge priority and the base MAC address of the bridge. Last TCN The time in day:hour:minute:second format since the topology of the selected MST instance last changed.
PAGE 127
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The updated configuration is sent to the switch. Configuration changes take effect immediately. Delete an MST Instance  To delete an MST instance: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 128
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Switching > STP > Advanced > MST Port Configuration. The Status page displays.
PAGE 129
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the nonconfigurable information on the page. Table 28. MST port status information Field Description Auto-calculated Port Path Cost Displays whether the path cost is automatically calculated (Enabled) or not (Disabled). Path cost is calculated based on the link speed of the port if the configured value for Port Path Cost is zero.
PAGE 130
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 View STP Statistics You can view information about the number and type of bridge protocol data units (BPDUs) transmitted and received on each port.  To view Spanning Tree statistics: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2.
PAGE 131
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 29. STP Statistics (continued) Field Description MSTP BPDUs Received Number of MSTP BPDUs received at the selected port. MSTP BPDUs Transmitted Number of MSTP BPDUs transmitted from the selected port. Configure Multicast Multicast IP traffic is traffic that is destined to a host group. Host groups for IPv4 multicast are identified by class D addresses, which range from 224.0.0.0 to 239.255.255.255.
PAGE 132
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 7. Click the Go button. If the address exists, the entry is displayed. An exact match is required. The following describes the nonconfigurable information on the page. Table 30. MFDB table information Field Description MAC Address The multicast MAC address for which you requested data. VLAN ID The VLAN ID to which the multicast MAC address is related. Type This displays the type of the entry.
PAGE 133
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the nonconfigurable information on the page. Table 31. MFDB Statistics information Field Description Max MFDB Table Entries The maximum number of entries that the Multicast Forwarding Database table can hold. Most MFDB Entries Since Last Reset The largest number of entries that were present in the Multicast Forwarding Database table since last reset.
PAGE 134
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure IGMP Snooping You can configure the parameters for IGMP snooping, which is used to build forwarding lists for multicast traffic.  To configure IGMP snooping: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 135
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 8. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. 9. To refresh the page with the latest information about the switch, click the Update button. The following table describes the nonconfigurable information on the page. Table 32.
PAGE 136
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select one or more interfaces by taking one of the following actions: • To configure a single interface, select the check box associated with the port, or type the port number in the Go To Interface field and click the Go button. • To configure multiple interfaces with the same settings, select the check box associated with each interface.
PAGE 137
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 View the IGMP Snooping Table You can view all of the entries in the Multicast Forwarding Database that were created for IGMP snooping.  To view the entries in the IGMP snooping table: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2.
PAGE 138
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 33. IGMP Snooping Table information (continued) Field Description Description The text description of this multicast table entry. Possible values are Management Configured, Network Configured, and Network Assisted. Interface The list of interfaces that are designated for forwarding (Fwd) and filtering (Flt) for the associated address.
PAGE 139
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • Host Timeout. Specify the time that the switch must wait for a report for a particular group for the specified VLAN ID. The valid range is the value in the Maximum Response Time plus 1 to 3600 seconds. The default is 260 seconds. • Maximum Response Time.
PAGE 140
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 IGMP Snooping Querier Overview IGMP snooping requires that one central switch or router periodically query all end-devices on the network to announce their multicast memberships. This central device is the IGMP querier. The IGMP query responses, known as IGMP reports, keep the switch updated with the current multicast group membership on a port-by-port basis.
PAGE 141
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • Snooping Querier IP Address. Enter the snooping querier IP address to be used as the source address in periodic IGMP queries. This address is used when no address is configured on the VLAN on which a query is being sent. • IGMP Version. Specify the IGMP protocol version used in periodic IGMP queries. The range is 1 to 2. The default is 2. • Query Interval(secs).
PAGE 142
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 7. Configure the following settings: • VLAN ID. The VLAN ID for which the IGMP snooping querier is to be enabled. • • Querier Election Participate Mode. Enable or disable querier this mode: - Disable. Upon seeing another querier of the same version in the VLAN, the snooping querier moves to the non-querier state. - Enable.
PAGE 143
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the nonconfigurable information on the page. Table 34. Querier VLAN Status information Field Description VLAN ID The VLAN ID on which IGMP snooping querier is administratively enabled and the VLAN exists in the VLAN database. Operational State The operational state of the IGMP snooping querier on a VLAN. It can be in any of the following states: • Querier.
PAGE 144
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The default password is password. The System Information page displays. 5. Select Switching > Multicast > Static Multicast Address > Multicast Group Configuration. 6. From the VLAN ID menu, select the VLAN ID. 7. In the Multicast Address field, enter the multicast MAC address that must become the group identifier. 8. Click the Add button. The multicast group is added.
PAGE 145
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Switching > Multicast > Static Multicast Address > Multicast Group Configuration. The Multicast Group Configuration page displays. 6.
PAGE 146
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. From the VLAN ID menu, select the VLAN ID for the VLAN in which the multicast group is located. If a name is associated with the VLAN, the name displays in the VLAN Name field. 7. From the Multicast Address menu, select the MAC address that identifies the multicast group. 8. Select which type of interfaces display onscreen: • To display physical ports only, click the 1 link.
PAGE 147
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 11. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. Configure the Multicast Forward All Option After IGMP snooping is enabled, multicast packets are forwarded only to the members of multicast groups.
PAGE 148
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • To display LAGs only, click the LAG link. • To display both physical ports and LAGs, click the All link. 8. Select one or more interfaces by taking one of the following actions: • To configure a single interface, select the check box associated with the interface, or type the interface number in the Go To Interface field and click the Go button.
PAGE 149
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Switching > Address Table > Basic > Address Table. 6. Use the Search menu and field to search for a MAC address, VLAN ID, or interface number: • Search by MAC Address.
PAGE 150
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 36. MAC Address Table information (continued) Field Description Interface The interface upon which this address was learned. Status The status of this entry. The meanings of the values are as follows: • Static. The value of the corresponding instance was added by the system or a user and cannot be relearned. • Learned. The value of the corresponding instance was learned, and is being used. • Management.
PAGE 151
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The updated configuration is sent to the switch. Configuration changes take effect immediately. Configure a Static MAC Address  To configure a static MAC address: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 152
4. Configure Quality of Service 4 In a switch, each physical port consists of one or more queues for transmitting packets on the attached network. Multiple queues per port are often provided to give preference to certain packets over others based on user-defined criteria. When a packet is queued for transmission in a port, the rate at which it is serviced depends on how the queue is configured and possibly the amount of traffic present in the other queues of the port.
PAGE 153
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Manage Class of Service The Class of Service (CoS) queueing feature lets you directly configure certain aspects of switch queueing. This provides the desired QoS behavior for different types of network traffic when the complexities of DiffServ are not required. The priority of a packet arriving at an interface can be used to steer the packet to the appropriate outbound CoS queue through a mapping table.
PAGE 154
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The System Information page displays. 5. Select QoS > CoS > Basic > CoS Configuration. 6. Either configure the same CoS trust mode settings for all CoS-configurable interfaces or configure CoS settings per interface: • To configure the same CoS trust mode settings for all CoS configurable interfaces, do the following: a. Select the Global radio button. b.
PAGE 155
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure CoS Interface Settings for an Interface You can configure the trust mode for one or more interfaces and apply an interface shaping rate to all interfaces or to a specific interface.  To configure CoS settings for an interface: 1. Connect your computer to the same network as the switch.
PAGE 156
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 8. From the Interface Trust Mode menu, select one of the following trust mode options for ingress traffic on the selected interfaces: • Untrusted. Do not trust any CoS packet marking at ingress. • 802.1p. The eight priority tags that are specified in IEEE 802.1p are p0 to p7. The QoS setting lets you map each of the eight priority levels to one of seven internal hardware priority queues. The default is 802.1p.
PAGE 157
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select QoS > CoS > Advanced > Interface Queue Configuration. 6. Click the LAG link to display all LAG interfaces or click the All link to display both all physical and all LAG interfaces. 7.
PAGE 158
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The Queue Management Type field displays the queue depth management technique that is used for queues on the interface. By default, this method is Taildrop, irrespective of your selection from the Scheduler Type menu. 11. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. 802.
PAGE 159
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. In the 802.1p to Queue Mapping table, map each of the eight 802.1p priorities to a queue (internal traffic class). The 802.1p Priority row contains traffic class selectors for each of the eight 802.1p priorities to be mapped. The priority goes from low (0) to high (7). For example, traffic with a priority of 0 is for most data traffic and is sent using best effort.
PAGE 160
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. For each DSCP value, select from the corresponding Queue menu which internal traffic class must be mapped to the DSCP value. The traffic class is the hardware queue for a port. Higher traffic class values indicate a higher queue position. Before traffic in a lower queue is sent, it must wait for traffic in higher queues to be sent.
PAGE 161
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 DiffServ Configuration Overview To use DiffServ for QoS, you must enable DiffServ (see Enable the DiffServ Mode and View the DiffServ Status on page 161) and define the following categories and their criteria: 1. Class. Create classes and define class criteria (see Configure a DiffServ Class on page 163). 2. Policy.
PAGE 162
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 3. In the address field of your web browser, enter the IP address of the switch. If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select QoS > DiffServ > Basic > DiffServ Configuration. 6.
PAGE 163
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 37. DiffServ Status information (continued) Field Description Policy Attributes table The number of configured policy attributes (attached to the policy class instances) out of the total allowed on the switch. Service table The number of configured services (attached to the policies on specified interfaces) out of the total allowed on the switch.
PAGE 164
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The Class Name field also lists all the existing DiffServ class names, from which one can be selected for modification or deletion. 7. From the Class Type menu, select the class type. The switch supports only the class type value All, which means that all the various match criteria defined for the class are satisfied for a packet match. All signifies the logical AND statement of all the match criteria.
PAGE 165
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 values for the Class of Service match criterion in the range 0 to 7 from which one can be selected. • VLAN. Select this radio button to require a packet’s VLAN ID to match a VLAN ID or a VLAN ID within a continuous range. If you configure a range, a match occurs if a packet’s VLAN ID is the same as any VLAN ID within the range. The VLAN value is in the range of 1–4093. • Ethernet Type.
PAGE 166
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • Destination IP. Select this radio button to require a packet’s destination IP address to match the specified IP address. After you select the radio button, use the following fields to configure the destination IP address match criteria: - Address. The destination IP address format to match in dotted-decimal. - Mask.
PAGE 167
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Rename an Existing DiffServ Class  To rename an existing DiffServ class: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 168
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The Class Name page displays. 6. Click the class name, which is a hyperlink. The page on which you can change the class configuration displays. 7. Change the class configuration as needed. 8. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. Delete a DiffServ Class  To delete a DiffServ class: 1.
PAGE 169
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch. If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5.
PAGE 170
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 10. From the Assign Queue menu, select the queue to which packets of this policy class must be assigned. This is an integer value in the range 0 to 7. 11. Configure the policy attributes: • Drop. Select this radio button to require each inbound packet to be dropped. • Mark VLAN CoS. Select this radio button to specify the VLAN priority, which you must select from the menu.
PAGE 171
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 12. If you select the Simple Policy radio button, you can specify the traffic policing style for the class: • Color Mode. From the menu, select one of the following options: - Color Blind. This is the default selection. Color classes do not apply. Note: A valid color class contains a single, non-excluded match criterion for the CoS, IP DSCP, or IP Precedence option.
PAGE 172
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the nonconfigurable information on the page. Table 39. DiffServ policy configuration policy attributes Field Description Policy Name Displays the name of the DiffServ policy. Policy Type Displays type of the policy as In. Member Class Name Displays the name of the class instance within the policy. Rename an Existing DiffServ Policy  To rename an existing DiffServ policy: 1.
PAGE 173
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 3. In the address field of your web browser, enter the IP address of the switch. If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select QoS > DiffServ > Advanced > Policy Configuration.
PAGE 174
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure the DiffServ Service Interface You can activate a policy on an interface. Attach a DiffServ Policy to an Interface  To attach a DiffServ policy to an interface: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 175
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 7. From the Policy Name menu, select a policy name. 8. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. The following table describes the nonconfigurable information on the page. Table 40. Service Interface Configuration information Field Description Direction Shows that the traffic direction of this service interface is In.
PAGE 176
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 View DiffServ Service Statistics You can display service-level statistical information about all interfaces to which DiffServ policies are attached.  To view the DiffServ service statistics: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2.
PAGE 177
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 41. DiffServ Service Statistics information (continued) Field Description Discarded Packets A count of the total number of packets discarded for all class instances in this service policy for any reason due to DiffServ treatment. This is the overall count per interface, per direction. The discarded packets are supported in the inbound direction but not in the outbound direction.
PAGE 178
5.
PAGE 179
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure the Management Security Settings You can configure the login password, Remote Authorization Dial-In User Service (RADIUS) settings, Terminal Access Controller Access Control System (TACACS) settings, and authentication lists. Change the Password You can change the login password.  To change the login password for the management interface: 1. Connect your computer to the same network as the switch.
PAGE 180
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The entered password is displayed in dots. 9. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. Note: If you forget the password and are unable to log in to the switch management interface, press the Factory Defaults button on the front panel of the switch for more than five seconds.
PAGE 181
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Security > Management Security > RADIUS > Global Configuration. The Current Server IP Address field is blank if no servers are configured (see Configure a RADIUS Authentication Server on the Switch on page 182). The switch supports up to three RADIUS servers.
PAGE 182
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 8. From he Accounting Mode menu, select to disable or enable RADIUS accounting on the server. The default is Disabled. 9. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. The following table describes the nonconfigurable information on the page. Table 42.
PAGE 183
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. In the Server Address field, specify the IP address of the RADIUS server. 7. In the Authentication Port field, specify the UDP port number the server uses to verify the RADIUS server authentication. The valid range is from 1 to 65535. The default is 1812. 8. From the Secret Configured menu, select Yes. You must select Yes before you can configure the RADIUS secret.
PAGE 184
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Field Description Access Requests The number of RADIUS access-request packets sent to this server. This number does not include retransmissions. Access Retransmissions The number of RADIUS access-request packets retransmitted to this server. Access Accepts The number of RADIUS access-accept packets, including both valid and invalid packets, that were received from this server.
PAGE 185
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The default password is password. The System Information page displays. 5. Select Security > Management Security > RADIUS > Server Configuration. The Server Configuration page displays. 6. Select the check box next to the server IP address. 7. Modify the configuration for the selected server. 8. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately.
PAGE 186
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure a RADIUS Accounting Server You can view and configure various settings for a RADIUS accounting server on the network. Add a RADIUS Accounting Server to the Switch  To add a RADIUS accounting server to the switch and view the RADIUS accounting server statistics: 1. Connect your computer to the same network as the switch.
PAGE 187
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 11. Click the Add button. The server is added to the switch. 12. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. 13. The following table describes the nonconfigurable information in the Accounting Server Statistics table on the page. Field Description Accounting Server Address The accounting server associated with the statistics.
PAGE 188
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Modify the Settings for a RADIUS Accounting Server on the Switch  To modify the settings for a RADIUS accounting server on the switch: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 189
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The Accounting Server Configuration page displays. 6. Click the Delete button. The RADIUS accounting server is removed. 7. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. Configure TACACS+ TACACS+ provides a centralized user management system, while still retaining consistency with RADIUS and other authentication processes.
PAGE 190
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. In the Key String field, specify the authentication and encryption key for TACACS+ communications between the switch and the TACACS+ server. The valid range is 0–128. The key must match the key configured on the TACACS+ server. 7. In the Connection Timeout field, specify the maximum number of seconds allowed to establish a TCP connection between the switch and the TACACS+ server. 8. Click the Apply button.
PAGE 191
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The priority determines the order in which the TACACS+ servers are contacted when attempting to authenticate a user. A value of 0 is the highest priority. The valid range is 0–65535. 8. In the Port field, specify the authentication port value for TACAS+ server sessions. It must be within the range 0–65535. If you do not specify a value, the switch uses the standard TCP port 49 for sessions with the server. 9.
PAGE 192
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select Security > Management Security > Authentication List > HTTP Authentication List. 6. Select the check box next to the httpList name. 7. From the menu in the 1 column, select the authentication method that must be used first in the selected authentication login list.
PAGE 193
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure an HTTPS Authentication List You can configure the default login list for secure HTTP (HTTPS).  To configure an HTTPS authentication list: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 194
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • TACACS+. The user’s ID and password are authenticated using the TACACS+ server. If you select RADIUS or TACACS+ as the first method and an error occurs during the authentication, the switch attempts user authentication Method 2. • None. The authentication method is unspecified. This option is only available for Method 2 and Method 3. 8.
PAGE 195
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select Security > Access > HTTP > HTTP Configuration. 6. In the HTTP Session Soft Timeout field, specify the number of minutes an HTTP session can be idle before a time-out occurs. The value must be in the range of 0–60 minutes. The default is 5 minutes. The currently configured value is shown when the web page is displayed.
PAGE 196
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Security > Access > HTTPS > HTTPS Configuration. 6. Select the HTTPS Admin Mode Enable or Disable radio button.
PAGE 197
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The updated configuration is sent to the switch. Configuration changes take effect immediately. Manage Certificates You can manage certificates. Generate an SSL Certificate  To generate an SSL certificate: 1. Connect your computer to the same network as the switch.
PAGE 198
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Delete an SSL Certificate  To delete an SSL certificate: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 199
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 3. In the address field of your web browser, enter the IP address of the switch. If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Security > Access > HTTPS > Certificate Download.
PAGE 200
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure Access Control Access control allows you to configure a profile and set access rules. Configure an Access Control Profile You can set -up a security access profile.  To configure an access profile: 1. Connect your computer to the same network as the switch.
PAGE 201
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The updated configuration is sent to the switch. Configuration changes take effect immediately. 9. To refresh the page with the latest information about the switch, click the Update button. The following table describes the nonconfigurable information on the page. Table 43. Access profile configuration profile summary Field Description Rule Type The action performed when the rules are matched.
PAGE 202
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. From the Rule Type menu, select Permit or Deny to permit or deny access when the selected rules are matched. A Permit rule allows access by traffic that matches the rule criteria. A Deny rule blocks traffic that matches the rule criteria. 7. From the Service Type menu, select the access method to which the rule is applied. The policy is restricted by the selected access method.
PAGE 203
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure Global 802.1X Settings You can configure global port access control settings on the switch.  To globally enable all 802.1X features: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 204
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Manage Port Authentication You can enable and configure port access control on one or more ports. Configure 802.1X Settings for a Port  To configure 802.1X settings for a port: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2.
PAGE 205
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 - Unauthorized. The system denies the selected interface system access by moving the interface into unauthorized state. The switch cannot provide authentication services to the client through the interface. - MAC based. This mode allows multiple supplicants connected to the same port to each authenticate individually.
PAGE 206
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the nonconfigurable information on the page. Table 44. Port authentication status information Field Description Control Direction The control direction for the specified port, which is always Both. The control direction dictates the degree to which protocol exchanges take place between supplicant and authenticator.
PAGE 207
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Security > Port Authentication > Advanced > Port Authentication. The Port Authentication page displays. 6. Select the check box associated with the port to initialize. 7. Click the Initialize button. 802.
PAGE 208
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 View the Port Summary You can view summary information about the port-based authentication settings for each port.  To view the port summary: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 209
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the nonconfigurable information on the page. Table 45. Port summary Field Description Port The port for which the settings are displayed in the table row. Control Mode This field indicates the configured control mode for the port. Possible values are as follows: • Force Unauthorized. The authenticator port access entity (PAE) unconditionally sets the controlled port to unauthorized.
PAGE 210
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure Traffic Control You can configure MAC filters, storm control, port security, protected port, and private VLAN settings. Manage MAC Filtering You can create MAC filters that limit the traffic that is allowed into specified ports on the switch. Create a MAC Filter  To create a MAC filter: 1. Connect your computer to the same network as the switch.
PAGE 211
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. From the MAC Filter menu, select Create Filter. If you did not configure any filters, this is the only option available. 7. From the VLAN ID menu, select the VLAN that must be used with the MAC address. 8. In the MAC Address field, specify the MAC address of the filter in the format XX:XX:XX:XX:XX:XX.
PAGE 212
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 MAC Filter Summary You can view the MAC filters that are configured on the switch.  To view the MAC filter summary: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 213
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2  To configure storm control settings: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 214
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 7. In the Storm Control section, from the Ingress Control Mode menu, select the mode of broadcast affected by storm control: • Disabled. Storm control is disabled. This is the default setting. • Unknown Unicast. If the rate of incoming unknown Layer 2 unicast traffic (that is, traffic for which a destination lookup failure occurs) increases beyond the configured threshold on an interface, the traffic is dropped.
PAGE 215
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Security > Traffic Control > Port Security > Port Security Configuration. 6. To enable port security on the switch, select the Port Security Mode Enable radio button. The default is Disable. 7. Click the Apply button. The updated configuration is sent to the switch.
PAGE 216
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Static locking allows you to specify a list of MAC addresses that are allowed on a port. The behavior of packets is the same as for dynamic locking: only packets with an allowable source MAC address can be forwarded.  To configure port security settings: 1. Connect your computer to the same network as the switch.
PAGE 217
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 7. Specify the following settings: • Port Security. Enable or disable the port security feature for the selected interfaces The default is Disable. • Max Learned MAC Address. Specify the maximum number of dynamically learned MAC addresses on the selected interfaces. • Max Static MAC Address. Specify the maximum number of statically locked MAC addresses on the selected interfaces. • Enable Violation Traps.
PAGE 218
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 For more information, see Configure a Port Security Interface on page 215. 9. Select Security > Traffic Control > Port Security > Security MAC Address. 10. From the Port List menu, select the individual interface. The Dynamic MAC Address Table displays the MAC addresses and their associated VLANs that were learned on the selected port. The fields are described in the following table.
PAGE 219
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch. If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Security > Traffic Control > Protected Port.
PAGE 220
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 A rule can identify protocols, source, and destination IP and MAC addresses, and other packet-matching criteria. 3. Use the ID number to assign the ACL to a port or to a LAG (see Configure MAC Bindings on page 231 or Configure IP ACL Interface Bindings on page 244). To view ACL configuration examples, see Access Control Lists (ACLs) on page 294.
PAGE 221
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. From the ACL Type menu, select the type of ACL. You can select from the following ACL types: • ACL Based on Destination MAC. Creates an ACL based on the destination MAC address, destination MAC mask, and VLAN. • ACL Based on Source MAC. Creates an ACL based on the source MAC address, source MAC mask, and VLAN. • ACL Based on Destination IPv4.
PAGE 222
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • True. Signifies that all packets must match the selected ACL and rule and are either permitted or denied. In this case, since all packets match the rule, the option of configuring other match criteria is not offered. 10. Specify the additional match criteria for the selected ACL type. The rest of the rule match criteria fields available for configuration depend on the selected ACL type.
PAGE 223
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 c. In the VLAN ID field, specify which VLAN must be compared against the information in an Ethernet frame. Valid range of values is 1 to 4093. Either a VLAN range or VLAN can be configured. d. In the Binding Configuration section, from the Direction menu, select the packet filtering direction for the ACL. Only the inbound direction is valid. e.
PAGE 224
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Delete an ACL Rule  To delete an ACL rule: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 225
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 For information about the ACL Wizard, see Use the ACL Wizard to Create a Simple ACL on page 220. Configure a MAC ACL A MAC ACL consists of a set of rules that are matched sequentially against a packet. When a packet meets the match criteria of a rule, the specified rule action (Permit or Deny) is taken, and the additional rules are not checked for a match.
PAGE 226
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The MAC ACL Table displays the number of ACLs currently configured in the switch and the maximum number of ACLs that can be configured. The current size is equal to the number of configured IPv4 plus the number of configured MAC ACLs. 6. In the Name field, specify a name for the MAC ACL. The name string can include alphabetic, numeric, hyphen, underscore, or space characters only.
PAGE 227
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Delete a MAC ACL  To delete a MAC ACL: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 228
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The default password is password. The System Information page displays. 5. Select Security > ACL > Basic > MAC Rules. The following figure does not show all columns. 6. From the ACL Name menu, select the MAC ACL. 7. In the Sequence Number field, enter a whole number in the range of 1 to 10 to identify the rule. 8.
PAGE 229
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 14. In the Destination MAC Mask field, specify the destination MAC address mask that must be compared against the information in an Ethernet frame. The valid format is xx:xx:xx:xx:xx:xx. The BPDU keyword can be specified using a destination MAC mask of 00:00:00:ff:ff:ff. 15. From the EtherType Key menu, select the EtherType value that must be compared against the information in an Ethernet frame.
PAGE 230
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 five-minute report interval is used for the switch. A trap is not issued if the ACL rule hit count is zero for the interval. This field is only supported for a deny action. 21. Click the Add button. The rule is added. Change the Match Criteria for a MAC Rule  To change the match criteria for a MAC rule: 1. Connect your computer to the same network as the switch.
PAGE 231
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Security > ACL > Basic > MAC Rules. The MAC Rules page displays. 6. Select the check box that is associated with the rule. 7. Click the Delete button. The rule is removed. Configure MAC Bindings You can assign MAC ACL lists to ACL priorities and interfaces.
PAGE 232
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. From the ACL ID menu, select an ACL. The fixed selection from the Direction menu is Inbound, which means that MAC ACL rules are applied to traffic entering the interface. 7. In the Sequence Number field, optionally specify a number to indicate the order of the access list relative to other access lists already assigned to the interface and direction. A low number indicates high precedence order.
PAGE 233
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the columns in the Interface Binding Status table on the page. Table 48. Interface Binding Status table Field Description Interface The interface of the ACL assigned. Direction The selected packet filtering direction for the ACL. ACL Type The type of ACL assigned to the selected interface and direction.
PAGE 234
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The binding is removed. The following table describes the nonconfigurable information on the page. Table 49. MAC Binding Table Field Description Interface The interface of the ACL assigned. Direction The selected packet filtering direction for the ACL. ACL Type The type of ACL assigned to the selected interface and direction.
PAGE 235
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The System Information page displays. 5. Select Security > ACL > Advanced > IP ACL. The previous figure shows an example. The IP ACL page shows the current size of the ACL table compared to the maximum size of the ACL table. The current size is equal to the number of configured IPv4 ACLs plus the number of configured MAC ACLs. The maximum size is 100.
PAGE 236
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Delete an IP ACL  To delete an IP ACL: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 237
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 3. In the address field of your web browser, enter the IP address of the switch. If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Security > ACL > Advanced > IP Rules.
PAGE 238
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 - Deny. Drop packets that meet the ACL criteria. • Egress Queue. If the selection form the Action menu is Permit, you can specify the hardware egress queue identifier that is used to handle all packets matching this IP ACL rule. The range of queue IDs is 0 to 7. • Logging. If the selection form the Action menu is Deny, you can enable logging for the ACL by selecting the Enable radio button.
PAGE 239
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select Security > ACL > Advanced > IP Rules. The IP Rules page displays. 6. From the ACL ID menu, select the ACL that includes the rule that you want to modify. 7. In the Basic ACL Rule Table, click the rule. The rule is a hyperlink. The Standard ACL Rule Configuration page displays. 8. Modify the basic IP ACL rule criteria. 9. Click the Apply button. The updated configuration is sent to the switch.
PAGE 240
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Configure Rules for an Extended IP ACL You can define rules for extended IP-based ACLs. The access list definition includes rules that specify whether traffic that is matching the criteria is forwarded normally or discarded. Note: An implicit deny all rule is included at the end of an ACL list.
PAGE 241
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 8. Configure the following match criteria for the rule: • Sequence Number. Enter a whole number in the range of 1 to 10 that is used to identify the rule. An extended IP ACL can contain up to 10 rules. • Action. Select the ACL forwarding action, which is one of the following: - Permit. Forward packets that meet the ACL criteria. - Deny. Drop packets that meet the ACL criteria. • Egress Queue.
PAGE 242
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • Src. In the Src field, enter a source IP address, using dotted-decimal notation, to be compared to a packet’s source IP address as a match criterion for the selected IP ACL rule: Enter an IP address or an IP address range. You can enter a relevant wildcard mask to apply this criteria. If this field is left empty, it means any. The wildcard mask determines which bits are used and which bits are ignored.
PAGE 243
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Select Other from the menu to enter a port number. If you select Other from the menu but leave the field blank, it means any. • Service Type. Select a service type match condition for the extended IP ACL rule. The possible options are IP DSCP, IP precedence, and IP TOS, which are alternative methods to specify a match criterion for the same service type field in the IP header.
PAGE 244
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The System Information page displays. 5. Select Security > ACL > Advanced > IP Extended Rules. The IP Rules page displays. 6. From the ACL ID menu, select the ACL that includes the rule that you want to modify. 7. In the Extended ACL Rule Table, click the rule. The rule is a hyperlink. The Extended ACL Rule Configuration page displays. 8. Modify the extended IP ACL rule criteria. 9. Click the Apply button.
PAGE 245
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2  To bind an IP ACL to one or more interfaces: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 246
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 highest sequence number currently in use for this interface and direction is used. The valid range is 1–4294967295. 8. To add the selected ACL to a port or LAG, in the Ports table or LAG table, click the port or LAG so that a check mark displays. You can add the ACL to several ports and LAGs. The Ports and LAG tables display the available and valid interfaces for ACL binding.
PAGE 247
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The System Information page displays. 5. Select Security > ACL > Advanced > Binding Table. 6. To delete an IP ACL-to-interface binding, do the following: a. Select the check box next to the interface. b. Click the Delete button. The binding is removed. The following table describes the fields in the IP ACL Binding Table on the page. Table 51. IP ACL Binding Table Field Description Interface The interface.
PAGE 248
6.
PAGE 249
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Monitor the Switch and the Ports You can display information about the amount and type of traffic that is transmitted from and received by the switch.
PAGE 250
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Click the Update button to refresh the page with the latest information about the switch. 7. Click the Clear button to clear all the statistics counters, resetting all switch summary and detailed statistics to default values. The discarded packets count cannot be cleared. The following table describes the switch statistics on the page. Table 52.
PAGE 251
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 52. Switch statistics (continued) Field Description Receive Packets Discarded The number of inbound packets that were chosen to be discarded, even though no errors were detected, in order to prevent their being delivered to a higher-layer protocol. A possible reason for discarding a packet could be to free up buffer space.
PAGE 252
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 View Port Statistics You can display a summary of per-port traffic statistics on the switch.  To view port statistics: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 253
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The following table describes the per-port statistics on the page. Table 53. Port statistics Field Description Interface This object indicates the interface of the interface table entry associated with this port on an adapter. Total Packets Received Without Errors The total number of packets received that were without errors.
PAGE 254
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Reset Counters for a Specific Interface  To reset the counters for a specific interface: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 255
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Monitoring > Ports > Port Detailed Statistics. The following figure does not show all fields on the Port Detailed Statistics page. 6. From the Interface menu, select the interface with the statistics to view. 7.
PAGE 256
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 54. Detailed port statistics (continued) Field Description Port Channel ID If the port is a member of a port channel, the port channel’s interface ID and name are shown. Otherwise, Disable is shown. Port Role Each MST bridge port that is enabled is assigned a port role for each spanning tree. The port role is one of the following values: Root, Designated, Alternate, Backup, Master, or Disabled.
PAGE 257
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 54. Detailed port statistics (continued) Field Description Packets RX and TX 256-511 Octets The total number of packets (including bad packets) received or transmitted that were between 256 and 511 octets in length inclusive (excluding framing bits but including FCS octets).
PAGE 258
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 54. Detailed port statistics (continued) Field Description Multicast Packets Received The total number of good packets received that were directed to a multicast address. This number does not include packets directed to the broadcast address. Broadcast Packets Received The total number of good packets received that were directed to the broadcast address. This does not include multicast packets.
PAGE 259
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 54. Detailed port statistics (continued) Field Description Packets Transmitted 65-127 Octets The total number of packets (including bad packets) received that were between 65 and 127 octets in length inclusive (excluding framing bits but including FCS octets).
PAGE 260
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 54. Detailed port statistics (continued) Field Description Multiple Collision Frames A count of the number of successfully transmitted frames on a particular interface for which transmission is inhibited by more than one collision. Excessive Collision Frames A count of frames for which transmission on a particular interface fails due to excessive collisions.
PAGE 261
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The System Information page displays. 5. Select Monitoring > Ports > EAP Statistics. 6. To refresh the page with the latest information about the switch, click the Update button. 7. To clear the counters for a specific port, select the check box associated with the port and click the Clear button. 8.
PAGE 262
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 55. EAP statistics Field Description EAPOL Length Error Frames This displays the number of EAPoL frames that were received by this Received authenticator in which the frame type is not recognized. EAP Response/ID Frames Received This displays the number of EAP response/identity frames that were received by this authenticator.
PAGE 263
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select the check boxes that are associated with the physical ports for which you want to test the cables. 7. Click the Apply button. A cable test is performed on all selected ports. The cable test might take up to two seconds to complete. If the port forms an active link with a device, the cable status is always Normal.
PAGE 264
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 For the message log, only the latest 64 entries are displayed on the page.  To configure the memory log settings: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 265
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The updated configuration is sent to the switch. Configuration changes take effect immediately. The Memory Log table displays on the Memory Log page. The Total number of Messages field displays the number of messages the system logged in memory. Only the 64 most recent entries are displayed on the page. The rest of the page displays the Memory Log messages.
PAGE 266
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Manage the Flash Log The flash log is a persistent log, that is, is a log that is stored in persistent storage. Persistent storage survives across platform reboots. The first log type is the system startup log. The system startup log stores the first 32 messages received after system reboot. The second log type is the system operation log. The system operation log stores messages received during system operation.
PAGE 267
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 - Error (3). A device error occurred, such as a port being offline. - Warning (4). The lowest level of a device warning. - Notice (5). Normal but significant conditions. Provides the network administrators with device information. - Informational (6). Provides device information. - Debug (7). Provides detailed information about the device. 8.
PAGE 268
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Monitoring > Logs > Server Log. The Server Log page displays. 6. Next to Admin Status, select one of the following: • Enable. Send log messages to all configured hosts (syslog collectors or relays) using the values configured for each host. • Disable.
PAGE 269
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select Monitoring > Logs > Server Log. The Server Log Configuration page displays. 6. Specify the following settings: • IP Address Type. Specify the IP address type of the host, which can be IPv4, IPv6, or DNS. • Host Address. Specify the IP address or host name of the syslog host. • Port. Specify the port on the host to which syslog messages must be sent. The default port number is 514. • Severity Filter.
PAGE 270
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Monitoring > Logs > Server Log. The Server Log Configuration page displays. 6. Select the check box that is associated with the host. 7. Change the information as needed. 8. Click the Apply button. The updated configuration is sent to the switch.
PAGE 271
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2  View the trap logs and clear the counters: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 272
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 57. Trap Logs information (continued) Field Description System Up Time The time when this trap occurred, expressed in days, hours, minutes, and seconds, since the last reboot of the switch. Trap Information identifying the trap. Configure Port Mirroring Port mirroring selects the network traffic for analysis by a network analyzer. This is done for specific ports of the switch.
PAGE 273
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. Select an Admin Mode radio button: • True. Port mirroring is enabled. • False. Port mirroring is enabled. 7. From the Destination Port menu, select the destination port to which port traffic must be copied. You can configure only one destination port on the switch. The port functions as a probe port and receives traffic from all configured source ports. If no port is configured, None is displayed.
PAGE 274
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • Tx and Rx. Monitors transmitted and received packets. • Rx. Monitors received (ingress) packets only. • Tx. Monitors transmitted (egress) packets only. 12. Click the Apply button. The updated configuration is sent to the switch. Configuration changes take effect immediately. The Status field indicates the interface status.
PAGE 275
7.
PAGE 276
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Reboot the Switch You can reboot the switch from the web management interface.  To reboot the switch: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3.
PAGE 277
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2  To reset the switch to the factory default settings: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch.
PAGE 278
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 2. Launch a web browser. 3. In the address field of your web browser, enter the IP address of the switch. If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Maintenance > Upload > TFTP File Upload. 6.
PAGE 279
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 9. In the Server Address field, enter the IP address of the server in accordance with the format indicated by the server address type. The default is the IPv4 address 0.0.0.0. 10. In the Transfer File Path field, specify the path on the TFTP server where you want to save the file. You can enter up to 32 characters. Include the backslash at the end of the path. A path name with a space is not accepted.
PAGE 280
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. From the File Type menu, select the type of file: • Archive. The archive is the system software image, which is saved in one of two flash sectors called images (image1 and image2). The active image stores the active copy, while the other image stores a second copy. The device boots and runs from the active image. If the active image is corrupted, the system automatically boots from the nonactive image.
PAGE 281
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 You can also download files by using HTTP. See Download a File to the Switch Using HTTP on page 282 for additional information.  To download a file to the switch from a TFTP server: 1. Connect your computer to the same network as the switch. You can use a WiFi or wired connection to connect your computer to the network, or connect directly to a switch that is off-network using an Ethernet cable. 2.
PAGE 282
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Note: We recommended that you do not overwrite the active image. If you do so, the switch displays a warning that you are trying to overwrite the active image. 8. From the Server Address Type menu, select the format for the TFTP Server IP field: • IPv4. Indicates that the TFTP server address is an IP address in dotted-decimal format. This is the default setting. • DNS.
PAGE 283
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 The default password is password. The System Information page displays. 5. Select Maintenance > Download > HTTP File Download. 6. From the File Type menu, select the type of file: • Archive. The system software image, which is saved in one of two flash sectors called images (image1 and image2). The active image stores the active copy, the other image stores a second copy.
PAGE 284
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Note: After a file transfer is started, wait until the page refreshes. When the page refreshes, the option to select a file option is no longer available, indicating that the file transfer is complete. Note: After a text configuration file is downloaded, the switch applies the configuration automatically. Manage Files The system maintains two versions of the switch software in permanent storage.
PAGE 285
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 5. Select Maintenance > File Management > Dual Image Configuration. 6. From the Image Name menu, select the image that is not the image displayed in the Current-active field. The Current-active field displays the name of the active image. 7. To specify a name for the selected image, enter one in the Image Description field. 8. Select the Activate Image check box. 9. Click the Apply button.
PAGE 286
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. From the Image Name menu, select the image that is not the image displayed in the Current-active field. The Current-active field displays the name of the active image. You cannot delete the active image. 7. Select the Delete Image check box. 8. Click the Apply button. The image is removed. Display the Dual Image Status You can display information about the active and backup images on the switch.
PAGE 287
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Perform Troubleshooting You can send a ping and perform a memory dump. Ping an IPv4 Address You can specify that the switch must send a ping request to a specified IP address. You can use this to check whether the switch can communicate with a particular IP station. When you click the Apply button, the switch sends a specified number of ping requests and the results are displayed.
PAGE 288
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. In the IP Address/Host Name field, enter the IP address or host name of the device that must be pinged. 7. In the Count field, enter the number of echo requests that must be sent. The default is 3. The range is 1 to 15. 8. In the Interval field, enter the time between ping packets in seconds. The default is 3 seconds. The range is 1 to 60. 9. In the Size field, enter the size of the ping packet.
PAGE 289
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Maintenance > Troubleshooting > Ping IPv6. 6. In the IPv6 Address/Hostname field, enter the IPv6 address or host name of the station that must be pinged. The format is xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx. The maximum number of characters is 255. 7.
PAGE 290
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 If you do not know the IP address of the switch, see Change the Default IP Address of the Switch on page 9. The login window opens. 4. Enter the switch’s password in the Password field. The default password is password. The System Information page displays. 5. Select Maintenance > Troubleshooting > Remote Diagnostics. The Remote Diagnostics page displays. 6. Select the Enable radio button. 7. Click the Apply button.
PAGE 291
A. Configuration Examples This appendix contains information about how to configure the following features. The appendix contains the following sections: • Virtual Local Area Networks (VLANs) • Access Control Lists (ACLs) • Differentiated Services (DiffServ) • 802.
PAGE 292
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Virtual Local Area Networks (VLANs) A local area network (LAN) can generally be defined as a broadcast domain. Hubs, bridges, or switches in the same physical segment or segments connect all end node devices. End nodes can communicate with each other without the need for a router. Routers connect LANs together, routing the traffic to the appropriate port.
PAGE 293
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • Packets leaving the switch are either tagged or untagged, depending on the setting for that port’s VLAN membership properties. A U for a given port means that packets leaving the switch from that port are untagged. Inversely, a T for a given port means that packets leaving the switch from that port are tagged with the VLAN ID that is associated with the port.
PAGE 294
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 untagged packet as it leaves port 6. For port 5, the outgoing packet leaves as a tagged packet with VLAN ID 20. Access Control Lists (ACLs) ACLs ensure that only authorized users can access specific resources while blocking off any unwarranted attempts to reach network resources.
PAGE 295
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • Match Every. False • CoS. 0 • Destination MAC. 01:02:1A:BC:DE:EF • Destination MAC Mask. 00:00:00:00:FF:FF • EtherType. User Value. • Source MAC. 02:02:1A:BC:DE:EF • Source MAC Mask. 00:00:00:00:FF:FF • VLAN ID. 2 For more information about MAC ACL rules, see Configure MAC ACL Rules on page 227. 3.
PAGE 296
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 For additional information about IP ACL rules, see Configure Rules for a Basic IP ACL on page 236. 3. Click the Add button. 4. On the IP Rules page, create a second rule for IP ACL 1 with the following settings: • Sequence Number. 2 • Action. Permit • Match Every. True 5. Click the Add button. 6.
PAGE 297
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Two basic types of QoS are supported: • Integrated Services. Network resources are apportioned based on request and are reserved (resource reservation) according to network management policy (RSVP, for example). • Differentiated Services. Network resources are apportioned based on traffic classification and priority, giving preferential treatment to data with strict timing requirements.
PAGE 298
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 DiffServ Traffic Classes With DiffServ, you define which traffic classes to track on an ingress interface.
PAGE 299
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 definition to convey some QoS characteristics to downstream switches that do not routinely look at the DSCP value in the IP header. • Policing. A method of constraining incoming traffic associated with a particular class so that it conforms to the terms of the TCS. Special treatment can be applied to out-of-profile packets that are either in excess of the conformance specification or are nonconformant.
PAGE 300
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 • Source Mask. 255.255.255.0. • Source L4 Port. Other, and enter 4567 as the source port value. • Destination IP Address. 192.12.2.0. • Destination Mask. 255.255.255.0. • Destination L4 Port. Other, and enter 4568 as the destination port value. For more information about this page, see Configure a DiffServ Class on page 163. 4. Click the Apply button. 5.
PAGE 301
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 point of attachment to the LAN, such as a port of a MAC bridge and an association between stations or access points in IEEE 802.11 wireless LANs. The IEEE 802.11 standard describes an architectural framework within which authentication and consequent actions take place.
PAGE 302
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 controls the authorized/unauthorized state of the controlled port depending on the outcome of the RADIUS-based authentication process. Figure 1. 802.1X authentication roles 802.1X Example Configuration This example shows how to configure the switch so that 802.1X-based authentication is required on the ports in a corporate conference room (g5–g8).
PAGE 303
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 6. On the RADIUS Server Configuration page (see Add a Primary RADIUS Authentication Server to the Switch on page 182), configure a RADIUS server with the following settings: • Server Address. 192.168.10.23 • Secret Configured. Yes • Secret. secret123 • Active. Primary For more information, see Configure RADIUS Servers on page 180. 7. Click the Add button. 8.
PAGE 304
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 ensures that frames with a given VLAN ID are assigned to one and only one of the MSTIs or the IST within the region, that the assignment is consistent among all the networking devices in the region, and that the stable connectivity of each MSTI and IST at the boundary of the region matches that of the CST.
PAGE 305
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 MSTP Example Configuration This example shows how to create an MSTP instance from the switch. The example network includes three different switches that serve different locations in the network. In this example, ports 1/0/1–1/0/5 are connected to host stations, so those links are not subject to network loops. Ports 1/0/6–1/0/8 are connected across switches 1, 2, and 3. Figure 2.
PAGE 306
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 If you do not specify a root bridge and all switches are assigned the same bridge priority value, the switch with the lowest MAC address is elected as the root bridge (see Configure CST Settings on page 119). 5. On the CST Port Configuration page, select ports 1/0/1–1/0/8 and select Enable from the STP Status menu (see Configure CST Port Settings on page 121). 6. Click the Apply button. 7.
PAGE 307
B. Specifications and Default Settings This appendix describes the default settings for the switch and for its software features.
PAGE 308
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Switch Default Settings The following table describes the switch default settings. Table 59. Switch default settings Feature Default IP address 192.168.0.239 Subnet mask 255.255.255.0 Default gateway 192.168.0.
PAGE 309
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 59.
PAGE 310
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 60.
PAGE 311
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 60.
PAGE 312
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 60. General feature default settings (continued) Feature Name/Setting Default 802.1p to Queue Mapping (802.
PAGE 313
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 60.
PAGE 314
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Table 60. General feature default settings (continued) Feature Name/Setting Default 802.1p to Queue Mapping (802.
PAGE 315
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Port Characteristics The following table describes the port characteristics. Table 62. Port characteristics Feature Sets Supported Default Energy Efficient Ethernet (EEE) All ports Disabled Auto negotiating speed and full/half duplex All ports Auto negotiation Auto MDI/MDIX for cross over cables on all ports Enabled 802.
PAGE 316
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 Quality of Service Settings The following table describes the Quality of Service settings. Table 64. Quality of Service settings Feature Sets Supported Default Number of queues 8 N/A 802.1p 1 Enabled DSCP 1 Disabled Egress Rate limiting All ports Disabled Security Settings The following table describes the security settings. Table 65. Security settings Feature Sets Supported Default 802.
PAGE 317
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2 System Management Settings The following table describes the system management settings. Table 66.
