(Continued)
DescriptionField
From the menu, select the packet data protocol (PDP):
• IPV4. The mobile broadband network uses IPv4 only. This is the default setting.
• IPV6. The mobile broadband network uses IPv6 only.
• IPV4V6. The mobile broadband network uses either IPv4 or IPv6.
PDP
From the menu, select the PDP that is used for roaming:
• None. The modem does not use the specified PDP for roaming. This is the default setting.
• IPV4. The mobile broadband network uses IPv4 only for roaming.
• IPV6. The mobile broadband network uses IPv6 only for roaming.
• IPV4V6. The mobile broadband network uses either IPv6 or IPv6 for roaming.
PDP Roaming
9. Click the Save button.
The new APN profile displays on the page but is not the active profile until you select it as such (see
Select an APN Profile on page 34).
Select an APN Profile
Although rarely required, you can select an APN profile manually.The modem uses the selected APN profile
to establish a connection with the mobile broadband network of the service provider.
To select an APN profile as the active profile:
1. Launch a web browser from a device that is connected to the modem.
The device can be a computer that is directly connected to the modem or a client from a router that is
connected to the modem.
2. In the address field of your browser, enter http://192.168.5.1.
The limited Dashboard page displays.
3. If you did not select the Remember me check box when you logged in previously, enter the modem
password in the Sign In field.
See the modem label for the default password.
4. Click the Sign In button.
The full Dashboard page displays.
5. Select Settings > Mobile > APN.
The APN page displays the available APN profiles.
If you did not yet add a custom APN profile, the default profile is the active APN profile and you cannot
select another profile until you add a custom profile (see View APN Profiles or Add a Custom APN Profile
on page 32).
Manage the Mobile Broadband Connection
34
LTE Modem LB1120 and LB1121
