After you reset the modem to factory default settings, the password is the one that is shown on the modem
label, the LAN IP address is 192.168.5.1, and Router mode is enabled. For a list of factory default settings,
see Factory Default Settings on page 91.
Use the Reset Button
CAUTION:
This process erases all settings that you configured in the modem.
To reset the modem to factory default settings with the Reset button:
1. On the back of the modem, locate the recessed Reset button.
2. Insert a straightened paper clip into the hole and press for at least five seconds.
If you press the button for less than five seconds, the modem might just restart rather
than resetting to factory default settings.
Note
3. Release the button.
The modem resets and restarts.This process takes about one minute.
Use the Modem’s Web Pages to Reset the Modem to Factory
Defaults
CAUTION:
This process erases all settings that you configured in the modem.
To reset the modem to factory default settings with the modem’s web pages:
1. Launch a web browser from a device that is connected to the modem.
The device can be a computer that is directly connected to the modem or a client from a router that is
connected to the modem.
2. In the address field of your browser, enter http://192.168.5.1.
The limited Dashboard page displays.
3. If you did not select the Remember me check box when you logged in previously, enter the modem
password in the Sign In field.
See the modem label for the default password.
4. Click the Sign In button.
The full Dashboard page displays.
