WFS709TP ProSafe Smart Wireless Switch Software Administration Manual

Configuring WLANS 5-9

v1.0, June 2007

7. Click Apply.

Advanced WLAN Configuration in the Browser Interface

The Advanced WLAN configuration pages allow you to configure the following features:

• Global SSID and radio parameters that affect all APs in the network

• SSID and radio parameters for APs in specific locations in the network

The parameters that you configure for global or location-specific SSID and radio configurations

are identical. However, if the same parameters are configured for global and location-specific APs

for a WLAN, the location-specific values override global values.

For example, if you set the maximum number of clients to 30 in the global configuration for

WLAN-01 and set the maximum number of clients to 15 for location 1.2.1 for the same SSID, the

APs in location 1.2.1 will have a maximum of 15 clients.

Configuring Global Parameters

To configure global parameters that affect all APs in the network:

Figure 5-2
