WFS709TP ProSafe Smart Wireless Switch Software Administration Manual

Configuring DHCP with Vendor-Specific Options A-3

v1.0, June 2007

Configuring Option 43

Option 43 returns the IP address of the master WFS709TP to a DHCP client. This information

allows the APs to auto-discover the master WFS709TP and obtain their configuration.

To configure option 43 on the Windows DHCP server:

1. On the DHCP server, open the DHCP server administration tool by clicking Start >

Administration Tools > DHCP.

2. Find your server and right-click on the scope to be configured under the server name. Click on

the Scope Options entry and select Configure Options.

3. In the Scope Options dialog box (Figure A-1), scroll down and select 043 Vendor Specific

Info.

4. In the Data Entry field, click anywhere in the area under the ASCII heading and enter the

following information:

ASCII: Loopback address of the master WFS709TP

5. Click OK to save the configuration.

Figure A-1
