WFS709TP ProSafe Smart Wireless Switch Software Administration Manual
4-6 RF Plan
v1.0, June 2007
Enter the following information:
• Building ID. The valid range for this field is any integer from 1 to 255.
• Building Name. The Building Name is an alphanumeric string up to 64 characters in length.
• Width and Length. Enter the rectangular exterior dimensions of the building. The valid range
for this field is any integer from 1 to a value corresponding to 1x10
12
.
If your building has an irregular shape, the width and length should represent the maximum
width and length of the overall footprint of the building as seen from above. Figure 4-4 shows
how to measure the coverage area for irregular shapes.
Figure 4-3
Figure 4-4
