Universal WiFi Range Extender WN3000RP User M anual 350 East Plumeria Drive San Jose, CA 95134 USA February 2013 202-10789-02 v1.
Universal WiFi Range Extender WN3000RP ©2011 NETGEAR, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of NETGEAR, Inc. Technical Support Thank you for choosing NETGEAR.
Table of Contents Chapter 1 Getting Started Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 How the Extender Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 When to Use Your Extender. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Positioning Your Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Connect a PC to the Extender with an Ethernet Cable . . . .
1. Getting Started 1 This chapter covers the following topics: • Hardware Features • How the Extender Works • Connect a PC to the Extender with an Ethernet Cable • Log In to the Extender • Use the Smart Wizard to Set Up the Extender For more information about the topics covered in this manual, visit the Support website at http://support.netgear.com.
Universal WiFi Range Extender WN3000RP Hardware Features Note: For best performance, position antennas pointing up. Device On/Off button WPS button Factory Reset button Ethernet port WPS Link Rate PC to Extender Status Figure 1. Extender The LEDs on the front show how the Extender is working: WPS. This LED indicates a WPS wireless connection. • - Solid green. There is wireless security (WPA or WPA2). - Blinking green. A WPS connection is in progress. • PC to Extender.
Universal WiFi Range Extender WN3000RP How the Extender Works The Extender works like a bridge between a wireless router and a computer or wireless device outside the wireless router’s range. To do this, the Extender has two main jobs: 1. The Extender connects to a wireless network that is up and running. When the Extender connects wirelessly to a network, it acts as a network client. This is similar to how a computer connects to a network. 2. The Extender acts as an access point for computers.
Universal WiFi Range Extender WN3000RP The Extender LEDs can help you tell if the extender is correctly set up and working as it should. • The best performance is delivered when both the Link Rate LED and the PC to Extender Connection LED are green. • A workable performance is delivered when the Link Rate LED is amber and the PC to Extender Connection LED is green. Positioning Your Extender The ideal location to place the Extender is half-way between your wireless router and your computer.
Universal WiFi Range Extender WN3000RP Connect a PC to the Extender with an Ethernet Cable Usually, you connect to the Extender wirelessly, but you can use its LAN port to connect a wired device such as an Ethernet-enabled gaming console, printer, or PC. Note: Before you connect wired devices or computers, first install and set up your Extender as described in the Universal WiFi Extender WN3000RP Installation Guide that came in the package. 1. Connect your computer to the Extender with an Ethernet cable.
Universal WiFi Range Extender WN3000RP 2. In the address field of your browser, enter http://www.mywifiext.net. You are prompted to enter a user name and password: If you do not see the log in prompt, make sure to include http:// when you type http://www.mywifiext.net in your browser. 3. Type admin for the user name. The default password is password. NETGEAR recommends that you set a more secure password after you log in (see Set the Password on page 23).
Universal WiFi Range Extender WN3000RP After installation, to use the Smart Wizard again: 1. Log in to the Extender as described previously. Note: Once you begin using the Smart Wizard, you must complete all of its steps before you can exit. 2. From the menu, select Setup Wizard. The following screen displays: This is the same Smart Wizard that displays during installation as described in the installation guide. 3.
Universal WiFi Range Extender WN3000RP 4. Enter the passphrase for your wireless network and click Continue. The next screen displays: 5. Make sure that the correct network name is shown, and then click Continue. The Extender connects to your existing wireless network.
Universal WiFi Range Extender WN3000RP The Extender’s wireless network name (SSID) changes to the name of your wireless network name with _EXT added to the end. The following screen displays: When this happens, your computer is automatically disconnected from the Extender wireless network. 6. If you want to use the same password to access the Extender’s wireless network that you use for wireless access to your existing network, click the copy password button. 7.
2. Extender Network Settings 2 To change settings, connect the Extender to your computer and use your Internet browser to go to http://www.mywifiext.net as described in Connect a PC to the Extender with an Ethernet Cable on page 8.
Universal WiFi Range Extender WN3000RP Connect the Extender to an Existing Network You can use this menu selection to wirelessly connect the Extender to your home network. 1. From the Extender menu at http://www.mywifiext.net, select Setup > Connect to an Existing Network. The Extender scans for wireless networks, and displays a list. If your wireless network is not on the list, and it is up and running, see Positioning Your Extender on page 7 for suggestions. 2.
Universal WiFi Range Extender WN3000RP To use the Extender WPS button to connect: 1. Locate the WPS button on the side of the Extender. WPS button 2. Press the Extender’s WPS button. For 2 minutes, the Extender attempts to add a wireless client (a computer or other wireless device) to its wireless network. 3. Within 2 minutes, press the WPS button on your wireless device, or follow the WPS instructions that came with your wireless device. Your wireless device is now connected to the Extender.
Universal WiFi Range Extender WN3000RP The Extender tries to find the wireless client (the computer) that is attempting to join the network. If you are using a WPS button, it tries for 2 minutes. If you are using a PIN, it tries for 4 minutes. 3. Go to your wireless computer. Use its WPS software to try to connect to the Extender. The first time you add a WPS client, WPS automatically sets the Extender’s wireless security to WPA2 + WPA with a random passphrase.
Universal WiFi Range Extender WN3000RP • None. This is an open wireless network. Any wireless computer or device is allowed to join this network. • WEP. WEP is an older standard, and is less secure than WPA or WPA2. WEP uses encryption keys and data encryption for data security. You can select 64-bit or 128-bit encryption. • WPA-PSK [TKIP]. WPA is more secure than WEP. When using wireless computers or devices that support WPA, you can enter a passphrase to join the extender’s wireless network.
Universal WiFi Range Extender WN3000RP Note: Not all wireless computers support passphrase key generation. If your computer does not support the passphrase, then you will need to type the encryption key in order to join the wireless network. • Key 1–Key 4. These values are not case-sensitive. You can manually enter the four data encryption keys. These values must be identical on all computers and access points in your network. Enter 10 hexadecimal digits (any combination of 0–9, a–f, or A–F). 5.
Universal WiFi Range Extender WN3000RP - IP Address. The static IP address. - IP Subnet Mask. The subnet mask associated with the IP address. - Gateway IP Address. The IP address for the gateway. - Primary DNS. The primary domain name server (DNS). - Secondary DNS. The secondary domain name server (DNS). Status Screen When you connect to http://www.mywifiext.net, after the automatic firmware check, the Status screen displays.
Universal WiFi Range Extender WN3000RP Extender IP Info • MAC Address. The physical address of the Extender, as seen from the local area network (LAN). • IP Address. The IP address of the Extender. The default is 192.168.1.250. • DHCP Client. Identifies the network DHCP client on the wireless network. • IP Subnet Mask. The IP subnet mask associated with the LAN IP address of the Extender. The default is 255.255.255.0. • Gateway IP Address. he IP address of the wireless network gateway.
Universal WiFi Range Extender WN3000RP Table 1. Show Statistics Fields (Continued) Field Description Collisions The number of collisions on this port since reset or manual clear. Tx B/s The current line utilization—percentage of current bandwidth used on this port. Rx B/s The average line utilization for this port. Up Time The time elapsed since the last power cycle or reset. Poll Interval Specify the poll interval frequency.
Universal WiFi Range Extender WN3000RP correctly, you should back up the information to have it available if something goes wrong. When you back up the settings, they are saved as a file on your computer. You can restore the device’s settings from this file. Back Up Settings 1. Click Backup. Your browser extracts the configuration file from the Extender. 2. If you do not have your browser set up to save downloaded files automatically, locate where you want to save the file. 3.
Universal WiFi Range Extender WN3000RP Set the Password The user name to access the Extender is admin, and its default password is password. NETGEAR strongly recommends that you set a more secure password. From the Extender menu at http://www.mywifiext.net, select Maintenance > Set Password. The following screen displays: Type the old password, type the new password twice, and then click Apply.
Universal WiFi Range Extender WN3000RP CAUTION: Once you start the firmware upgrade, do not try to go online, turn off the Extender, shut down the computer, or do anything else to the Extender until it finishes restarting. Advanced Wireless Settings The Extender is already set up with the optimum settings. Do not alter these settings unless directed by NETGEAR support. Incorrect settings might disable the Extender unexpectedly.
3. Troubleshooting 3 Smart Wizard FAQs 1. When I connect to the network, Smart Wizard keeps asking me for my passphrase, and I am sure I’ve entered the correct passphrase. What can I do? It is very likely that the Extender is placed at the borderline of the range covered by the router. See Positioning Your Extender on page 7. 2. I got an error message in the Review Settings screen in the Smart Wizard.
Universal WiFi Range Extender WN3000RP - The best performance is delivered when both the Link Rate LED are green. Extender Connection LED and the PC to - A workable performance is delivered when the Link Rate LED is amber is green. PC to Extender Connection LED and the If you cannot get a wireless connection working, you can use an Ethernet cable to connect your computer to the Extender. See Connect a PC to the Extender with an Ethernet Cable on page 8.
A. Supplemental Information A Factory Settings You can press and hold the Factory Settings button on the side panel for 7 seconds. The Extender resets, and returns to its factory settings. Table 2. Factory Settings Smart Wizard Enabled Wireless Wireless communication Enabled Wireless Network Name (SSID) NETGEAR_EXT Security Disabled Transmission speed Auto1 Country/Region United States (varies by region) Operating mode 802.11n, 802.11g, 802.11b Data rate Up to 300 Mbps 1.
Universal WiFi Range Extender WN3000RP Technical Specifications Table 3. Technical Specifications Network protocol and standards compatibility Data and Routing Protocols: TCP/IP, DHCP server and client AC input 100-240V~, 0.3A (Max) Physical specifications • Dimensions: 112 x 74 x 45 mm (4.41 x 2.91 x 1.77 in) • Weight: 0.245 kg (0.
B. Compliance Notification B Regulatory Compliance Information This section includes user requirements for operating this product in accordance with National laws for usage of radio spectrum and operation of radio devices. Failure of the end-user to comply with the applicable requirements may result in unlawful operation and adverse action against the end-user by the applicable National regulatory authority.
Universal WiFi Range Extender WN3000RP FCC Caution • Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. • This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Universal WiFi Range Extender WN3000RP Table 4. EDOC in Languages of the European Community Language Statement English Hereby, NETGEAR Inc., declares that this Radiolan is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Español [Spanish] Por medio de la presente NETGEAR Inc. declara que el Radiolan cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Universal WiFi Range Extender WN3000RP Table 4. EDOC in Languages of the European Community Language Statement Suomi [Finnish] NETGEAR Inc. vakuuttaa täten että Radiolan tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Svenska [Swedish] Härmed intygar NETGEAR Inc. att denna Radiolan står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
