WFS709TP ProSafe Smart Wireless Switch Software Administration Manual

5-14 Configuring WLANS

v1.0, June 2007

• Power Management. Enables power management.

• Bootstrap Threshold. Number of heartbeat misses before an AP reboots.

• VoIP CAC Disconnect Extra Call. Enables disconnecting of calls that exceed the high

capacity threshold.

• RF Band. RF band in which the AP should operate: g = 2.4 GHz, a=5GHz.

Configuring Radio Settings

You can fine-tune radio settings on a per-radio (802.11a or 802.11b/g) basis.

To configure radio settings that affect all APs in the network, navigate to the Configuration >

Advanced > WLAN > Network > Radio page.

To configure radio settings for APs in a specific location in the network:

1. Navigate to the Configuration > Advanced > WLAN > Advanced page.

2. Click Add to add a new location.

3. Enter a location ID in the format building.floor.plan, where each value is an integer.

4. Click Add.

5. Select the 802.11b/g or 802.11a tab to configure radio settings (Figure 5-5).

Note: Selecting these options may affect roaming performance.
